Datalogic Magellan 2200VS User Manual

DataBar Expanded Enable
Product Reference Guide 283
DataBar Expanded Length 2
Length 2 is the maximum label length if in variable length mode, or the
second fixed length if in fixed length mode (see
DataBar Expanded
Length Control)
. Length includes the barcode’s check and data characters.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET DataBar Expanded LENGTH 2 below.
You’ll need to cover any unused bar codes on this and the facing
page to ensure that the scanner reads only the bar code you intend
to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired label length. A setting of 00 will ignore this length
(only one fixed length), otherwise, the selectable range for this
option is 01 to 74. Pad all single digit numbers with a leading zero
to yield a two-digit entry (01-74).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET DataBar Expanded LENGTH 2

Datalogic Magellan 2200VS Specifications

General

Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional.
Standard interfaces	USB, RS-232
Dimensions (WxDxH)	152 x 152 x 97 mm
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
