POWERSCAN® D8530
116
8 TECHNICAL FEATURES
PowerScan® D8530 Family Common Features
Electrical Features
Operating Voltage 5 to 30 V
Power Consumption
@ 5V
(Typical) 600 mA
@30V
(Typical) 100 mA
Communications Features
Standard Interfaces RS-232, Keyboard emulation AT IBM, USB COM emulation, USB
Keyboard emulation
Proprietary Interfaces USB Bulk, USB Generic HID
Environmental Features
Operating Temperature -10° to +55° C (+14° to +131° F)
Storage Temperature -20° to +70° C (-4° to +158° F)
Humidity 0 to 95% NC
Drop Resistance
2 m / 6.6 ft (over 50 drops to concrete)
IP Sealing
IP65
Mechanical Features
Dimensions
20.8 x 6.6 x 11 cm / 8.1 x 2.6 x 4.3 in
Weight 295 g / 10.4 oz (without cable)
Decoding Capability
1D Interleaved 2 of 5, Code 39, Code 32, Code 128, EAN 128,
Code93, UPC/EAN/JAN, Codabar, GS1 DataBar™
2D Aztec, PDF417, Micro PDF417, Macro PDF417, Maxicode,
DataMatrix (ECC200), QR, Composite Codes
Postal Codes PLANET, Japan Post, Australia Post, KIX Code, Royal Mail Code
(RM4SCC)
Imaging Options
Image 1280x1024 pixels (Full Resolution)
640 x 512 pixel format (Half Resolution);
Graphic Format JPEG, 256 gray levels
TIFF, 2, 16, 256 gray levels
Optical Features
Sensor 1280 x 1024 pixel element, 2D CMOS Array
Illuminator LED array
Wavelength In the range 630 ~ 670 nm
LED Safety Class Class 1 to EN 60825-1
Aiming System Visible Laser Diode
Wavelength 650 nm
Laser Safety Class Class 2 - EN 60825-1; Class II CDRH
Ambient light 0 - 100000 lux
