Datalogic QuickScan L QD2300 User Manual

Parts of the Scanner
Quick Reference Guide 3
Parts of the Scanner
Scanning Modes
The Scanner can operate in two modes:
Trigger Single Mode — Trigger button must be pressed to
emit the laser in order to a scan barcode.
or
Stand Mode — Scanner laser is in constant on state and no
trigger button press is required to scan a barcode.
To toggle between modes, scan the “Toggle Scan Mode”
barcode below.
Depending upon which mode the scanner currently is in,
scan the “Toggle Scan Mode” to switch from
Trigger Single
to
Stand , or from Stand to Trigger Single Mode .
Trigger
Scan
Window
LED
Nose
Boot
Toggle Scan Mode

Datalogic QuickScan L QD2300 Specifications

General

Brand	Datalogic
Model	QuickScan L QD2300
Category	Barcode Reader
Language	English
