Replacing the Scan Window
Quick Reference Guide 17
Replacing the Scan Window
If the Scan Window becomes scratched, broken or con-
taminated with heavy dust, replace it by removing the
Nose Boot and installing a new window. Datalogic offers a
replacement window as an orderable accessory.
To replace the Scan Window, first remove power from the
scanner then hold the scanner with the Scan Window fac-
ing up. Gently pull off the Nose Boot and tilt the scanner
to one side to remove the window.
Holding it by its edges, carefully place the clean replace-
ment Scan Window in position and secure it in place by
reinstalling the Nose Boot.
CAUTION
Proceed to the next step immediately. DO NOT
leave the interior of the scanner exposed.
To Next Page
