18
Linking/Unlinking Channels
Channels can be configured for stereo (linked) or dual mono (unlinked) operation. This option can be configured when you run
the Wizard or manually from the System menu.
NOTE: When linked, the parameters for both channels will be linked but AFS detection and filter placement will not.
In other words, both channels will share the same parameter settings but feedback will be detected and notched out
independently per channel. When clearing filters with the channels linked, both channels will be cleared.
To link/unlink channels manually:
1� From the Home Screen, press the BACK/MENU button.
2� Turn the DATA wheel to select the SYSTEM MENU option then press the DATA wheel to advance.
3� With the STEREO LINK option selected, press the DATA wheel.
4� Turn the DATA wheel to select the desired option – select YES for stereo linked operation or NO for unlinked operation.
5� Press the MENU/BACK button repeatedly to return to the Home Screen.
