DSE Model 7000 Series Control & Instrumentation System Operators Manual
Part No. 057-074 7000 Series OPERATING MANUAL ISSUE 2 02/05/2008 ADM
75
15.2 SENSOR WIRING RECOMMENDATIONS
15.2.1 EARTH RETURN SENSORS
Connection Name Terminal Number
Sensor common 15
NOTE:- . It is important that terminal 15 (sensor
common) is soundly connected to an earth point on the
ENGINE BLOCK, not within the control panel, and must be
a sound electrical connection to the sensor bodies.
NOTE:- . If you use PTFE insulating tape on the sensor
thread when using earth return sensors, ensure you do not
insulate the entire thread, as this will prevent the sensor
body from being earthed via the engine block.
Oil pressure Sensor 16
Coolant temperature
sensor
17
Fuel level sensor 18
Flexible Sensor
(Not fitted to 7200 series)
19
15.2.2 INSULATED RETURN SENSORS
Connection Name Terminal Number
Sensor common 15
NOTE:- . It is important that terminal 15 (sensor
common) is soundly connected to an earth point on the
ENGINE BLOCK, not within the control panel.
Oil pressure Sensor 16
Coolant temperature
sensor
17
Fuel level sensor 18
Flexible Sensor
(Not fitted to 7200 series)
19
15.3 CAN INTERFACE
Modules are fitted with the CAN interface as standard and are capable of receiving
engine data from engine CAN controllers compliant with the CAN standard.
CAN enabled engine controllers monitor the engines operating parameters such as
engine speed, oil pressure, engine temperature (among others) in order to closely
monitor and control the engine. The industry standard communications interface (CAN)
transports data gathered by the engine controller interface (CAN). This allows generator controllers such as the
DSE 73x0 range to access these engine parameters with no physical connection to the sensor device.
NOTE:- For further details for connections to CAN enabled engines and the functions available with
each engine type, refer to the manual Electronic Engines and DSE Wiring. Part No. 057-004
