Dell 3115CN User Manual

7 - 19
Chapter 7 Wiring Diagrams and Signal Information
Version 1 2006.11.21
Signal line name Description
CLOCK
DATA
Control signal of the EEPROM BELT
ADC SOL ON (L) +24VDC ON/OFF signal of the ADC SOLENOID
ADC SENSOR
Toner patch density data measured by the ADC SENSOR
(Analog value)
LED REM Remote signal of the LED of ADC SENSOR
ADC V MONI Control signal of the ADC SENSOR
DATA
CLOCK
Control signal of the EEPROM XPRO
TEMP.
Temperature data in the printer by the TEMP./HUM.
SENSOR (Analog value)
HUMI.
Humidity data in the printer by the TEMP./HUM. SENSOR
(Analog value)
ERASE K ON (L) +3.3VDC
ERASE Y/M/C ON (L) +3.3VDC
ON/OFF signal of the ERASE LAMP

Dell 3115CN Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Print speed (color, normal quality, A4/US Letter)	17 ppm
Digital sender	No
Maximum duty cycle	60000 pages per month
Number of print cartridges	4
Scanner type	Flatbed scanner
PC free copying	Yes
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	200
Multi-Purpose tray input capacity	150 sheets
Sound power level (standby)	40 dB
Sound pressure level (printing)	52 dB
Display	LCD
Market positioning	Business
Safety	IEC/EN60950-1:2001; IEC60825-1; CE Mark (EU); NEMKO; GS Mark; GOST & Hygienic; SASO; SABS; UL/cUL Listed; FDA/DHHS
Dimensions (WxDxH)	460 x 570 x 730 mm
Power requirements	220-240V, 47 - 63 Hz
Networking features	Ethernet 10/100 BaseT
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	1152 GB
Color all-in-one functions	print, scan
Compatible operating systems	Windows Vista/Vista x64, Microsoft Windows XP SP1-2, XP 64 bit, NT 4.0 SP6a, 2000 SP2-4, Server 2003 SP1, Server 2003 x64, Mac OS X, UNIX (SolarisTM 10, HP-UX11i), Linux (Red Hat 8/9, SuSE 9, TurboLinux 10)
Paper tray media types	Card stock, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	DellTCP/IP & UDP/IP (LPD, Port9100, IPP6, SMB6, Netware v 5, FTP, HTTP, HTTPS6, RARP, AutoIP, WINS6, SMTP, FTP, DDNS6, SNMP, DHCP, BOOTP, mDNS6); NetBEUI (SMB6); Netware P-server6; Ethertalk6; AppleTalk
Standard interfaces	USB 2.0
Bundled software	ScanSoft PaperPort v10, Dell Printer Configuration Web Tool, Dell Colour Track 2, Dell Toner Management System
Sustainability certificates	ENERGY STAR
Power consumption (off)	0 W
Power consumption (standby)	108 W
Power consumption (PowerSave)	18 W
Power consumption (average operating)	465 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	5 - 32 °C
Storage relative humidity (H-H)	15 - 80 %
Operating relative humidity (H-H)	15 - 85 %
Certification	CE; EN55022:1994 Class B+A1:1995+A2:1997; EN61000-3-2:2000+A2:2005; EN 61000-3-3:1995+A1:2001; EN55024:1998+A1:2001+A2:2003; FCC CFR; ICES-003; GOST; SABS
