6 Insert the standard tray.
7 Press .
241–245 paper jams
1 Pull out the tray indicated on the display.
2 Remove any jammed paper, and then insert the tray.
3 Press .
4 If the jam message persists for a 250-sheet or 550-sheet tray, then remove the tray from the printer.
5 Remove the jammed paper, and then insert the tray.
6 Press .
250 paper jam
1 Remove the paper from the multipurpose feeder.
Clearing jams
148
