Figure 32. Installing the speaker
Steps
1. Press the tab on the speaker and slide the speaker into the slot on the chassis until it snaps into place.
2. Connect the speaker cable to its connector (INT SPKR) on the system board.
Next steps
1. Install the side cover.
2. Follow the procedure in After working inside your computer.
Intrusion switch
Removing the intrusion switch
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
About this task
The following image indicates the location of the intrusion switch and provides a visual representation of the removal procedure.
74
Removing and installing Customer Replaceable Units (CRUs)
Restricted - Confidential
