15.Remove the two (M2x4.5) screws that secure the fan and heat-sink assembly to the palm-rest assembly.
16.Remove the three (M2x3) screws that secure the fan and heat-sink assembly to the palm-rest assembly.
17. Remove the five (M2x3) screws that secure the system board to the palm-rest assembly.
18.Remove the two (M2x3) screws that secure the left I/O-board to the palm-rest assembly.
19.Lift the system-board assembly from the palm-rest assembly and turn the system-board assembly over.
NOTE: When the system board is removed it is removed as an assembly consisting of:
• system board
• left I/O-board
• fan and heat-sink assembly
20.Remove the left I/O-board.
21. Remove the fan and heat-sink assembly.
Installing the system board
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the system board and provides a visual representation of the installation procedure.
45
