Clock Settings
Purpose:
To specify the clock settings.
Va lu e s:
Date Format Sets the date format; YYYY/MM/DD, MM/DD/YYYY, or DD/MM/YYYY.
Time Format Sets the time format; 24 Hour Clock or 12 Hour Clock.
Time Zone Sets the time zone.
Set Date Sets the current date.
Set Time Sets the current time.
Web Link Customization
Purpose:
To specify a link used for ordering consumables, which can be accessed from Order Supplies at: in the left frame.
Va lu e s:
Select Reorder URL Sets a URL to be linked to Order Supplies at:
Regular Displays the regular URL (http://accessories.us.dell.com/sna) that can be linked to Order Supplies
at:.
Premier Displays the premier URL (http://premier.dell.com) that can be linked to Order Supplies at:.
Print Server Settings
Use the Print Server Settings menu to set the type of printer interface and the necessary conditions for
communication.
The following tabbed pages are displayed in the top of the right frame.
Print Server Reports
The Print Server Reports tab includes the Print Server Setup Page and the E-Mail Server Setup Page.
Print Server Setup Page
Purpose:
To verify the current settings of TCP/IP (Transmission Control Protocol/Internet Protocol) protocol and printing
ports. On this page, you can only verify the settings of items. If you want to change the settings, go to the pages in
the Print Server Settings tab.
Va lu e s:
Ethernet
*1
Ethernet Settings Displays the current settings of Ethernet transmission rate and the duplex
settings.
Current Ethernet
Settings
Displays the current Ethernet settings.
MAC Address Displays the Media Access Control (MAC) address of the printer.
Dell™ Printer Configuration Web Tool
152

Table of Contents

Other manuals for Dell C2665dnf

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell C2665dnf and is the answer not in the manual?

Dell C2665dnf Specifications

General IconGeneral
Secure printingYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)27 ppm
Duplex print speed (black, normal quality, A4/US Letter)18 ppm
Copier resize25 - 400 %
Maximum number of copies99 copies
Time to first copy (black, normal)16 s
Time to first copy (color, normal)20 s
Copy speed (black, normal quality, A4)27 cpm
Scan toCloud, E-mail, FTP, SMB, USB
Maximum scan area216 x 356 mm
Output color depth24 bit
Image formats supportedJPG, TIF
Maximum scan resolution9600 x 9600 DPI
Document formats supportedPDF
Optical scanning resolution1200 x 1200 DPI
Faxing-
Modem speed33.6 Kbit/s
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle50000 pages per month
Recommended duty cycle700 - 4000 pages per month
Number of print cartridges4
Page description languagesPCL 5c, PCL 6, PCL XL, PDF 1.6, PostScript 3
Printer managementDell Printer Configuration Web Tool, Dell ColourTrack 2.2, Dell Toner Management System, Dell Open Print Driver (OPD), Dell OpenManage TM Printer Manager v2 (OMPM)
Security featuresIKev1, EWS, IPv4, Fax/I/O
Cabling technology10/100/1000Base-T(X)
Authentication methodNTLM, SNMP v3, LDAP Kerberos
Ethernet LAN data rates10, 100, 1000 Mbit/s
Online services supportedBox, Dropbox, Google Drive, Sky Drive
Mobile printing technologiesApple AirPrint, Dell Mobile Print, Google Cloud Print
Sound pressure level (printing)52.5 dB
Paper input typePaper tray
Total input capacity400 sheets
Total output capacity250 sheets
Maximum input capacity950 sheets
Envelopes sizesC5, DL, Monarch
Custom media width148.5 - 215.9 mm
Custom media length210 - 355.6 mm
Duplex media weight60 - 163 g/m²
Paper tray media typesCoated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5
ISO B-series sizes (B0...B9)B5
ISO C-series sizes (C0...C9)C5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 216 g/m²
Control typeTouch
Product colorBlack
Display diagonal4.3 \
Display resolution272 x 480 pixels
Market positioningBusiness
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantity2
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)14.5 W
Power consumption (PowerSave)3.5 W
Power consumption (average operating)2700 W
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supportedRedHat EL Linux 5.0
Other operating systems supportedNovell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supportedWindows Server 2003
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificatesBlue Angel, RoHS, ENERGY STAR
CertificationEC60950-1:2005, EN60950-1:2006/A11:2009/A1:2010/A12:2011; EC60825-1 2-nd (Laser); SEMKO (Nordic); CE Mark (EU); UL/cUL (UL60950-1 2); FDA/DHHS (21CFR, Chapter 1, Subchapter J), CE mark (EU countries) EMC/Safety Standard Class B, EN55022:2006, EN55022:2010, EN61000-3-2:2006, \\r + A1:2009 + A2:2009, EN 61000-3-3:2008, EN 55024:1998+A1:2001/A2:2003, FCC CFR Titl 47, Part 15 Class B (USA), ICES-003, Issue 4 (Canada), WHQL, Citrix, SAP, Novell, USB, WiFi, Google Cloud Print, Apple Airprint
Package depth686 mm
Package width570 mm
Package height706 mm
Package weight37500 g
Operating altitude0 - 3100 m
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)5 - 32 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)15 - 85 %
Weight and Dimensions IconWeight and Dimensions
Depth529.5 mm
Width439 mm
Height558 mm
