Dell C2665dnf User Manual

FAX Group (Confirm/Change, Create)
Purpose:
To view or edit the fax number group entries on the FAX Group page, or create a new entry. The following items are
in the dialog box that appears when you click Confirm / Change or Create on the FAX Group top page.
Va lu e s:
FAX Group ID Displays the selected group ID.
Name Allows you to view or edit the name assigned for the group ID, or enter a
new group name.
Delete
*1
Click this button to delete the current entry.
FAX Speed Dial Speed Dial List to: Selecting each button displays a list of entries for the group of speed dial
codes indicated on the button.
Speed Dial Displays the speed dial code. Select the check box on the left to add the
speed dial code in the group.
Name Displays the name registered for the speed dial code. (Not in Use) is
displayed when there is no registration.
Phone Number Allows you to view or edit the fax number of an entry registered under the
selected speed dial code, or enter a fax number for the new entry.
Apply New Settings Click this button to apply the new settings.
Restore Settings Click this button to restore the previous settings.
Back Click this button to return to the top page.
*1
This item is available only when you click Confirm / Change.
FAX Group (Delete)
Purpose:
To delete the fax number group entries registered on the FAX Group page. The following items are in the dialog box
that appears when you click Delete on the FAX Group top page.
Va lu e s:
ID Displays the selected group ID.
Name Displays the name assigned for the group ID.
Apply New Settings Click this button to apply the new settings.
Back Click this button to return to the top page.
Tray Management
Use the Tray Management menu to set the paper size and type of paper loaded in tray1 and the optional 550-sheet
feeder.
Va lu e s:
MPF Use Driver Sets whether to use the printer driver settings for the size and type of paper loaded in the MPF.
Settings for Print Job
MPF Paper Size
*1
Sets the size of paper loaded in the MPF.
MPF Paper Type
*1
Sets the type of paper loaded in the MPF.
MPF Custom Paper Sets the length of custom size paper loaded in the MPF.
Size - Y
*1
Dell™ Printer Configuration Web Tool 183

Dell C2665dnf Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	27 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	16 s
Time to first copy (color, normal)	20 s
Copy speed (black, normal quality, A4)	27 cpm
Scan to	Cloud, E-mail, FTP, SMB, USB
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, TIF
Maximum scan resolution	9600 x 9600 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 1200 DPI
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Recommended duty cycle	700 - 4000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PCL XL, PDF 1.6, PostScript 3
Printer management	Dell Printer Configuration Web Tool, Dell ColourTrack 2.2, Dell Toner Management System, Dell Open Print Driver (OPD), Dell OpenManage TM Printer Manager v2 (OMPM)
Security features	IKev1, EWS, IPv4, Fax/I/O
Cabling technology	10/100/1000Base-T(X)
Authentication method	NTLM, SNMP v3, LDAP Kerberos
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Box, Dropbox, Google Drive, Sky Drive
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print
Sound pressure level (printing)	52.5 dB
Paper input type	Paper tray
Total input capacity	400 sheets
Total output capacity	250 sheets
Maximum input capacity	950 sheets
Envelopes sizes	C5, DL, Monarch
Custom media width	148.5 - 215.9 mm
Custom media length	210 - 355.6 mm
Duplex media weight	60 - 163 g/m²
Paper tray media types	Coated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Control type	Touch
Product color	Black
Display diagonal	4.3 \
Display resolution	272 x 480 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	14.5 W
Power consumption (PowerSave)	3.5 W
Power consumption (average operating)	2700 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	RedHat EL Linux 5.0
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	Blue Angel, RoHS, ENERGY STAR
Certification	EC60950-1:2005, EN60950-1:2006/A11:2009/A1:2010/A12:2011; EC60825-1 2-nd (Laser); SEMKO (Nordic); CE Mark (EU); UL/cUL (UL60950-1 2); FDA/DHHS (21CFR, Chapter 1, Subchapter J), CE mark (EU countries) EMC/Safety Standard Class B, EN55022:2006, EN55022:2010, EN61000-3-2:2006, \\r + A1:2009 + A2:2009, EN 61000-3-3:2008, EN 55024:1998+A1:2001/A2:2003, FCC CFR Titl 47, Part 15 Class B (USA), ICES-003, Issue 4 (Canada), WHQL, Citrix, SAP, Novell, USB, WiFi, Google Cloud Print, Apple Airprint
Package depth	686 mm
Package width	570 mm
Package height	706 mm
Package weight	37500 g
Operating altitude	0 - 3100 m
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	5 - 32 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	529.5 mm
Width	439 mm
Height	558 mm
