Dell C2665dnf User Manual

15
Understanding the Tool Box Menus
The Tool Box allows you to view, specify, and diagnose the system settings.
NOTE: A Password dialog box appears the first time you try to change settings on Tool Box when Panel Lock is set on the
printer. In this case, input the password that you have already specified, and click OK to apply the settings.
Starting the Tool Box
1 Click Start → All Programs → Dell Printers → Dell C2665dnf Color Laser Multifunction Printer → Tool Box .
The screen to select the printer appears.
2 Click Network Connection or USB Connection , and then select the printer listed in Select From the Found
Printers
.
NOTE: If the printer is not listed in Select From the Found Printers when you click Network Connection, click Directly Input
IP Address/Host Name and enter the IP address of the printer. For details about how to verify the IP address of the printer,
see "Verifying the IP Settings."
NOTE: On Microsoft
®
Windows
®
XP or Windows Server
®
2003, printers using IPv6 addresses cannot be detected.
3 Click OK .
The
Tool Box opens.
The
Tool Box consists of the Printer Setting Reports , Printer Maintenance , and Diagnosis tabs.
Printer Setting Reports
The Printer Setting Reports tab includes the Printer Information, Menu Settings, Reports, TCP/IP Settings, Tray
Settings, Default Settings, Fax Settings, and Panel Language pages.
Printer Information
Purpose:
To display the system information of the printer.
Va lu e s:
Dell Service Tag Number Displays the service tag number of your printer.
Express Service Code Displays the express service code number.
Printer Serial Number Displays the serial number of your printer.
Printer Type Displays the type of printing for the printer. Color Laser is displayed normally.
Asset Tag Number Displays the asset tag number of your printer.
Memory Capacity Displays the memory capacity.
Processor Speed Displays the processing speed.
Firmware Version Displays the version of the controller.
MCU Firmware Version Displays the version of the Machine Control Unit (MCU) firmware.
Color Printing Speed Displays the speed for color printing.
Monochrome Printing Speed Displays the speed for monochrome printing.
Understanding the Tool Box Menus 185

Dell C2665dnf Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	27 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	16 s
Time to first copy (color, normal)	20 s
Copy speed (black, normal quality, A4)	27 cpm
Scan to	Cloud, E-mail, FTP, SMB, USB
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, TIF
Maximum scan resolution	9600 x 9600 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 1200 DPI
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	50000 pages per month
Recommended duty cycle	700 - 4000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PCL XL, PDF 1.6, PostScript 3
Printer management	Dell Printer Configuration Web Tool, Dell ColourTrack 2.2, Dell Toner Management System, Dell Open Print Driver (OPD), Dell OpenManage TM Printer Manager v2 (OMPM)
Security features	IKev1, EWS, IPv4, Fax/I/O
Cabling technology	10/100/1000Base-T(X)
Authentication method	NTLM, SNMP v3, LDAP Kerberos
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Box, Dropbox, Google Drive, Sky Drive
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print
Sound pressure level (printing)	52.5 dB
Paper input type	Paper tray
Total input capacity	400 sheets
Total output capacity	250 sheets
Maximum input capacity	950 sheets
Envelopes sizes	C5, DL, Monarch
Custom media width	148.5 - 215.9 mm
Custom media length	210 - 355.6 mm
Duplex media weight	60 - 163 g/m²
Paper tray media types	Coated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Control type	Touch
Product color	Black
Display diagonal	4.3 \
Display resolution	272 x 480 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	14.5 W
Power consumption (PowerSave)	3.5 W
Power consumption (average operating)	2700 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	RedHat EL Linux 5.0
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	Blue Angel, RoHS, ENERGY STAR
Certification	EC60950-1:2005, EN60950-1:2006/A11:2009/A1:2010/A12:2011; EC60825-1 2-nd (Laser); SEMKO (Nordic); CE Mark (EU); UL/cUL (UL60950-1 2); FDA/DHHS (21CFR, Chapter 1, Subchapter J), CE mark (EU countries) EMC/Safety Standard Class B, EN55022:2006, EN55022:2010, EN61000-3-2:2006, \\r + A1:2009 + A2:2009, EN 61000-3-3:2008, EN 55024:1998+A1:2001/A2:2003, FCC CFR Titl 47, Part 15 Class B (USA), ICES-003, Issue 4 (Canada), WHQL, Citrix, SAP, Novell, USB, WiFi, Google Cloud Print, Apple Airprint
Package depth	686 mm
Package width	570 mm
Package height	706 mm
Package weight	37500 g
Operating altitude	0 - 3100 m
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	5 - 32 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	529.5 mm
Width	439 mm
Height	558 mm
