Dell C5522QT User Manual

About your display | 11
Side view
1b
1c
2
4
5
3
9
8
6
7
1a
Label Description Use
1a HDMI 1 connector
Connect your computer with HDMI cable.1b HDMI 2 connector
1c HDMI 3 connector
2 DP connector Connect your computer with DP cable.
3 USB Type-C/
DisplayPort
Connect to your computer using the USB Type-C
cable.
The USB Type-C port offer the fastest transfer rate
USB 3.1 and the alternate mode with DP 1.2 support
the maximum resolution of 3840 x 2160 at 60 Hz, PD
20 V/4.5 A, 15 V/3 A, 9 V/3 A, 5 V/3 A.
NOTE: USB Type-C is not supported on Windows
versions that are prior to Windows 10.
4 RS232 connector Remote management and control of display via
RS232.
5 Audio line-out port Connect to external audio peripherals.
Only supports 2-channel audio.
NOTE: The audio line-out port does not support
headphones.

Dell C5522QT Specifications

General

Color gamut	72 %
Pixel pitch	0.315 x 0.315 mm
Response time	9 ms
Display diagonal	55 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Vertical scan range	24 - 75 Hz
Horizontal scan range	30 - 140 kHz
Contrast ratio (typical)	1300:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	138.787 cm
Active display area (W x H)	1209.6 x 680.4 mm
Number of simultaneous touchpoints	20
Product color	Black
Orientation	Horizontal
Product design	Interactive flat panel
Placement supported	Indoor
Bezel width (bottom)	44.7 mm
Panel mounting interface	400 x 300 mm
DVI port	No
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-C
USB ports quantity	8
HDMI ports quantity	3
VGA (D-Sub) input ports	0
RMS rated power	20 W
Speaker impedance	8 Ω
Speaker frequency range	120 - 20000 Hz
Number of built-in speakers	2
Purpose	Corporate
AC input voltage	100 - 240 V
Heat dissipation	249.43 BTU/h
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	300 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	73.1 W
Package weight	41700 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	78.7 mm
Width	1298.98 mm
Height	769.78 mm
Weight	34500 g
Display depth	- mm
Display width	1209.6 mm
Display height	680.4 mm
Display weight	- g
