Dell C5522QT User Manual

About your display | 13
Display specifications
Screen type Active matrix - TFT LCD
Panel Type In-plane switching Technology
Aspect ratio 16:9
Viewable image dimensions
Diagonal 138.787 cm (54.64 in.)
Active Area
Horizontal 1209.6 mm (47.62 in.)
Vertical 680.4 mm (26.79 in.)
Area 823011.84 mm
2
(1275.74 in.
2
)
Pixel pitch 0.315 mm x 0.315 mm
Pixel per inch (PPI) 81
Viewing angle
Horizontal 178
°
(typical)
Vertical 178
°
(typical)
Panel brightness 350 cd/m² (typical)
Contrast ratio 1300 to 1 (typical)
Display screen coating 7H, Anti-Smudge, Anti-Glare
Response Time 9 ms typical (G to G)
Color depth 1.07 Billion colors
Color gamut NTSC ( 72%)
Connectivity • 1 x DP 1.2
• 1 x USB Type-C (Alternate mode with DisplayPort
1.2, Power Delivery PD up to 90 W)
• 3 x HDMI 2.0
• 4 x USB 3.1 downstream port (1 x USB BC1.2
charging capability at 2 A (maximum))
• 3 x USB 3.1 upstream port
• 1 x Analog 2.0 audio line out (3.5 mm jack)
• 1 x RJ-45
• 1 x RS232
Border width (edge of display
to active area)
44.70 mm (1.76 in.) (Top)
44.70 mm (1.76 in.) (Left/Right)
44.70 mm (1.76 in.) (Bottom)

Dell C5522QT Specifications

General

Color gamut	72 %
Pixel pitch	0.315 x 0.315 mm
Response time	9 ms
Display diagonal	55 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Vertical scan range	24 - 75 Hz
Horizontal scan range	30 - 140 kHz
Contrast ratio (typical)	1300:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	138.787 cm
Active display area (W x H)	1209.6 x 680.4 mm
Number of simultaneous touchpoints	20
Product color	Black
Orientation	Horizontal
Product design	Interactive flat panel
Placement supported	Indoor
Bezel width (bottom)	44.7 mm
Panel mounting interface	400 x 300 mm
DVI port	No
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-C
USB ports quantity	8
HDMI ports quantity	3
VGA (D-Sub) input ports	0
RMS rated power	20 W
Speaker impedance	8 Ω
Speaker frequency range	120 - 20000 Hz
Number of built-in speakers	2
Purpose	Corporate
AC input voltage	100 - 240 V
Heat dissipation	249.43 BTU/h
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	300 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	73.1 W
Package weight	41700 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	78.7 mm
Width	1298.98 mm
Height	769.78 mm
Weight	34500 g
Display depth	- mm
Display width	1209.6 mm
Display height	680.4 mm
Display weight	- g
