32 | Setting up the display
Wall mounting
(Screw dimension: M8 x 35 mm).
Refer to installation instruction that comes with the 3rd party wall mount that
customer purchases. Vesa-compatible base mounting kit (400 x 300) mm.
1. Install Wall Plate to Wall.
2. Place the display panel on a soft cloth or cushion on a stable at table.
3. Attach the mounting brackets from the wall mounting kit to the display.
4. Install Display to Wall Plate.
5. Ensure display is mounted vertically with no tilt forward or backward and a leveler
is used to assist to mount the display.
NOTE:
• Do not attempt to wall mount the Touch Display by yourself. It should be
installed by qualified installers.
• Recommended Wall Mount for this Display can be found in the Dell
support website at dell.com/support.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket with
minimum weight/load bearing capacity of the product.

Dell C5522QT Specifications

General

Color gamut	72 %
Pixel pitch	0.315 x 0.315 mm
Response time	9 ms
Display diagonal	55 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Vertical scan range	24 - 75 Hz
Horizontal scan range	30 - 140 kHz
Contrast ratio (typical)	1300:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	138.787 cm
Active display area (W x H)	1209.6 x 680.4 mm
Number of simultaneous touchpoints	20
Product color	Black
Orientation	Horizontal
Product design	Interactive flat panel
Placement supported	Indoor
Bezel width (bottom)	44.7 mm
Panel mounting interface	400 x 300 mm
DVI port	No
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-C
USB ports quantity	8
HDMI ports quantity	3
VGA (D-Sub) input ports	0
RMS rated power	20 W
Speaker impedance	8 Ω
Speaker frequency range	120 - 20000 Hz
Number of built-in speakers	2
Purpose	Corporate
AC input voltage	100 - 240 V
Heat dissipation	249.43 BTU/h
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	300 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	73.1 W
Package weight	41700 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	78.7 mm
Width	1298.98 mm
Height	769.78 mm
Weight	34500 g
Display depth	- mm
Display width	1209.6 mm
Display height	680.4 mm
Display weight	- g
