Dell C5522QT User Manual

Operating the display | 57
Dell web management for displays
Before accessing the Dell Display Web Management feature, ensure the Ethernet is
working normally.
1 2 3 4 5 6 7
• Ethernet Enable
Touch and hold the touch key 5 on the front panel for 4 seconds to turn on , A
network icon
appears and is shown on the center for 4 seconds.
• Ethernet Disable
Touch and hold the touch key 5 on the front panel for 4 seconds to turn off , A
network icon
appears and is shown on the center for 4 seconds.
To access the Dell Display Web Management tool you need to set the IP Addresses for
your computer and the display.
1. Press the Menu key on the remote control to display the IP Address of the display,
or by navigating to OSD Menu > Others. By default, the IP Address is 10.0.50.100
Brightness/Contrast
Dell 55 Monitor
Others
Color
Display
Input Source
Audio
Menu
Personalize
DDC/CI
On
Display Info
Firmware
M2T101
HDMI CEC
LCD Conditioning
O
O
Reset Others
Factory Reset
IP Address
10.0.50.100
Service Tag
ABCDEFG
ENERGY STAR
®

Dell C5522QT Specifications

General

Color gamut	72 %
Pixel pitch	0.315 x 0.315 mm
Response time	9 ms
Display diagonal	55 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Vertical scan range	24 - 75 Hz
Horizontal scan range	30 - 140 kHz
Contrast ratio (typical)	1300:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	138.787 cm
Active display area (W x H)	1209.6 x 680.4 mm
Number of simultaneous touchpoints	20
Product color	Black
Orientation	Horizontal
Product design	Interactive flat panel
Placement supported	Indoor
Bezel width (bottom)	44.7 mm
Panel mounting interface	400 x 300 mm
DVI port	No
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-C
USB ports quantity	8
HDMI ports quantity	3
VGA (D-Sub) input ports	0
RMS rated power	20 W
Speaker impedance	8 Ω
Speaker frequency range	120 - 20000 Hz
Number of built-in speakers	2
Purpose	Corporate
AC input voltage	100 - 240 V
Heat dissipation	249.43 BTU/h
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	300 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	73.1 W
Package weight	41700 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	78.7 mm
Width	1298.98 mm
Height	769.78 mm
Weight	34500 g
Display depth	- mm
Display width	1209.6 mm
Display height	680.4 mm
Display weight	- g
