Dell C6522QT User Manual

| 3
Contents
Safety instructions..................................5
About your display ..................................6
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Product features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Identifying parts and controls . . . . . . . . . . . . . . . . . . . . . . . . .9
Front view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Back view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Side view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Bottom view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Display specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Touch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Support OS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Touch sensor input accuracy. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Speaker specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Resolution specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Preset display modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Electrical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Physical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Environmental characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Pin assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Plug-and-Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
LCD Display Quality and Pixel Policy . . . . . . . . . . . . . . . . . . . . 25
Maintenance guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning your display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Setting up the display ..............................26
Connecting your display. . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Optiplex (Optional). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
External PC connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Connecting the optiplex . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Cable management for third-party webcam with OptiPlex (Optional) . . . . . 30
Wall mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Contents | 3

Dell C6522QT Specifications

General

Color gamut	72 %
Pixel pitch	0.372 x 0.372 mm
Response time	9 ms
Display diagonal	64.53 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Vertical scan range	24 - 75 Hz
Horizontal scan range	30 - 140 kHz
Contrast ratio (typical)	1300:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	163.906 cm
Active display area (W x H)	1428.5 x 803.5 mm
Number of simultaneous touchpoints	20
DVI port	No
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-C
USB ports quantity	8
HDMI ports quantity	3
VGA (D-Sub) input ports	0
Orientation	Horizontal
Product color	Black
Product design	Interactive flat panel
Bezel width (top)	44.7 mm
Placement supported	Indoor
Panel mounting interface	400 x 400 mm
RMS rated power	40 W
Speaker impedance	8 Ω
Speaker frequency range	120 - 20000 Hz
Number of built-in speakers	2
Purpose	Corporate
AC input voltage	100 - 240 V
Heat dissipation	316.99 BTU/h
AC input frequency	50 - 60 Hz
Power consumption (max)	350 W
Power consumption (standby)	0.3 W
Power consumption (typical)	92.9 W
Package weight	55500 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	78.7 mm
Width	1517.88 mm
Height	892.92 mm
Weight	45200 g
Display width	- mm
Display weight	- g
