Operating the display | 57
Dell web management for displays
Before accessing the Dell Display Web Management feature, ensure the Ethernet is
working normally.
1 2 3 4 5 6 7
• Ethernet Enable
Touch and hold the touch key 5 on the front panel for 4 seconds to turn on , A network
icon appears and is shown on the center for 4 seconds.
• Ethernet Disable
Touch and hold the touch key 5 on the front panel for 4 seconds to turn off , A
network icon appears and is shown on the center for 4 seconds.
To access the Dell Display Web Management tool you need to set the IP Addresses for
your computer and the display.
1. Press the Menu key on the remote control to display the IP Address of the display,
or by navigating to OSD Menu > Others. By default, the IP Address is 10.0.50.100
Brightness/Contrast
Dell 65 Monitor
Others
Color
Display
Input Source
Audio
Menu
Personalize
DDC/CI
On
Display Info
Firmware
M2T101
HDMI CEC
LCD Conditioning
O
O
Reset Others
Factory Reset
IP Address
10.0.50.100
Service Tag
ABCDEFG
ENERGY STAR
®

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell C6522QT and is the answer not in the manual?

Dell C6522QT Specifications

General IconGeneral
Color gamut72 %
Pixel pitch0.372 x 0.372 mm
Response time9 ms
Display diagonal64.53 \
Display brightness350 cd/m²
Display technologyLCD
Native aspect ratio16:9
Native refresh rate60 Hz
Vertical scan range24 - 75 Hz
Horizontal scan range30 - 140 kHz
Contrast ratio (typical)1300:1
Display number of colors1.073 billion colors
Display diagonal (metric)163.906 cm
Active display area (W x H)1428.5 x 803.5 mm
Number of simultaneous touchpoints20
DVI portNo
USB version3.2 Gen 1 (3.1 Gen 1)
USB connector typeUSB Type-C
USB ports quantity8
HDMI ports quantity3
VGA (D-Sub) input ports0
OrientationHorizontal
Product colorBlack
Product designInteractive flat panel
Bezel width (top)44.7 mm
Placement supportedIndoor
Panel mounting interface400 x 400 mm
RMS rated power40 W
Speaker impedance8 Ω
Speaker frequency range120 - 20000 Hz
Number of built-in speakers2
PurposeCorporate
AC input voltage100 - 240 V
Heat dissipation316.99 BTU/h
AC input frequency50 - 60 Hz
Power consumption (max)350 W
Power consumption (standby)0.3 W
Power consumption (typical)92.9 W
Package weight55500 g
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth78.7 mm
Width1517.88 mm
Height892.92 mm
Weight45200 g
Display width- mm
Display weight- g
