3. Remove the slim ODD assembly.
About this task
The following images indicate the location of the slim ODD bracket and provides a visual representation of the removal procedure.
Steps
1. Pry the ODD bracket to release from the slots on the ODD.
2. Remove the ODD bracket off the ODD
Installing the slim ODD bracket
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the slim ODD bracket and provides a visual representation of the installation procedure.
Steps
1. Align and place the ODD bracket on the ODD slots.
2. Snap the ODD bracket into the ODD.
26
Disassembly and reassembly
