Option Description
Boot List Option:
• Legacy External Devices
• UEFI—The UEFI option is enabled by default.
Advanced Boot Options Allows you to select the Enable Legacy Option ROMs option, when in UEFI boot mode.
• Enable Legacy Option ROMs—The Enable Legacy Option ROMs option is enabled by default.
• Enable Attempt Legacy Boot
UEFI Boot Path Security This option controls whether or not the system will prompt the user to enter the Admin password when
booting a UEFI boot path from the F12 Boot Menu.
• Always, Except Internal HDD—The Always, Except Internal HDD option is enabled by default.
• Always, Except Internal HDD&PXE
• Always
• Never
Date/Time Allows you to set the date and time settings. Changes to the system date and time take effect
immediately.
.
System information
Table 4. System Configuration
Option Description
Integrated NIC Allows you to control the on-board LAN controller. The option Enable UEFI Network Stack is not
selected by default. The options are:
• Disabled
• Enabled
• Enabled w/PXE: The Enabled w/PXE option is enabled by default.
NOTE: Depending on the computer and its installed devices, the items that are listed
in this section may or may not be display.
Serial Port This option determines how the integrated serial port operates.
The options are:
• Disabled
• COM1: The COM1 option is enabled by default.
• COM2
• COM3
• COM4
SATA Operation This option enables you to configure the operating mode of the integrated SATA hard drive
controller.
The options are:
• Disabled—The SATA controllers are hidden
• AHCI—SATA is configured for AHCI mode
• RAID ON—SATA is configured to support RAID mode. This option is enabled by default.
Drives Allows you to enable or disable various drives on-board:
• SATA-0
• SATA-1
• SATA-2
• SATA-3
System setup 69
