2 Install the:
a 2.5 inch hard drive assembly
b Side cover
3 Follow the procedure in After working inside your computer.
Optional module
Removing optional module
1 Follow the procedure in Before working inside your computer.
2 Remove the :
a Side cover
b 2.5 inch hard drive assembly
3 To remove the optional card:
a Disconnect the optional-card cable from the connector on the system board [1].
b Remove the two (M2X3.5) screws and two screws that secure the optional card to the system chassis [2, 3].
34
Removing and installing components
