a. Place the heat sink assembly back onto the heat sink assembly bracket.
b. Rotate the heat sink assembly down towards the computer base and tighten the two capture screws.
NOTICE: Ensure that the heat sink is correctly seated and secure.

9. Replace the computer cover.

10. Connect your computer and devices to electrical outlets, and turn them on.
System Board
1
heat sink and fan shroud assembly
2
heat sink assembly bracket
3
captive screw housing (2)
NOTICE: To connect a network cable, first plug the cable into the network wall jack and then plug the cable into the computer.
