Dell E1916H User Manual

14 About Your Monitor
Plug and Play Capability
You can install the monitor in any Plug and Play compatible system. The monitor
automatically provides the computer with its Extended Display Identification Data (EDID)
using Display Data Channel (DDC) protocols so that the system can configure itself and
optimize the monitor settings. Most monitor installations are automatic. You can select
different settings if required.
Flat-Panel Specifications
Model number E1916H / E1916He E2016H E2216H
Screen type
Active matrix - TFT
LCD
Active matrix - TFT
LCD
Active matrix - TFT
LCD
Panel Type TN TN TN
Viewable image
Diagonal
470.1 mm
(18.51 inches)
494.1 ± 0.02 mm
(19.5 ± 0.05 inches)
546.1 mm
(21.5 inches)
Horizontal Active
Area
409.8 mm
(16.13 inches)
432.0 ± 1.92 mm
(17.0 ± 0.08 inches)
476.06 mm
(18.74 inches)
Vertical Active
Area
230.4 mm
(9.07 inches)
239.76 ± 3.42 mm
(9.44 ± 0.13 inches)
267.79 mm
(10.54 inches)
Area
94417.92 mm
2
(146.35 inches
2
)
102552.65 ± 1050
mm
2
(158.84± 1.56 inches
2
)
127484.10 mm
2
(197.52 inches
2
)
Pixel pitch 0.30 x 0.30 mm
0.248 ± 0.022 x 0.248
± 0.022 mm
0.248 x 0.248 mm
Viewing angle:
Horizontal 90° typical 170° typical 170° typical
Vertical 65° typical 160° typical 160° typical
Luminance
output
200 cd/m² (typical) 250 cd/m² (typical) 250 cd/m² (typical)
Contrast ratio 600 to 1 (typical) 1000 to 1 (typical) 1000 to 1 (typical)
Faceplate coating
Antiglare with hard-
coating 3H
Antiglare with hard-
coating 3H
Antiglare with hard-
coating 3H
Backlight LED edgelight system LED edgelight system LED light bar system
Response Time
5 ms typical (white to
black, black to white)
5 ms typical (white to
black, black to white)
5 ms typical (white to
black, black to white)
Color Depth 16.7 mil colors 16.7 mil colors 16.7 mil colors
Color Gamut 82 % (typical) * 86 % (typical) * 84 % (typical) *

Dell E1916H Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.3 x 0.3 mm
Aspect ratio	16:9
Backlight type	W-LED
Display surface	Matt
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Display technology	LED
Viewable size diagonal	470.1 mm
Viewing angle, vertical	65 °
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Display brightness (typical)	220 cd/m²
Supported graphics resolutions	1366 x 768
On/off switch	Yes
HDCP	-
HDMI ports quantity	0
Certification	CECP, TCO
Product color	Black
Market positioning	Business
LED indicators	Power
Panel mounting interface	100 x 100 mm
Input current	1 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	17 W
Power consumption (standby)	0.3 W
Power consumption (typical)	14 W
Power consumption (PowerSave)	10.4 W
Sustainability certificates	EPEAT Silver, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12191 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package weight	3600 g
Cables included	AC, DisplayPort

Weight and Dimensions

Depth (with stand)	167 mm
Height (with stand)	359 mm
Depth (without stand)	51.5 mm
Width (without stand)	445.4 mm
Height (without stand)	266 mm
Weight (without stand)	2260 g
