Dell E1916H User Manual

Troubleshooting 61
Image retention from
a static image left on
the monitor for a long
period of time
Faint shadow from the
static image displayed
appears on the screen
•Use the Power Management
feature to turn o the monitor at
all times when not in use (for more
information, see Power Management
Modes.
•Alternatively, use a dynamically
changing screensaver.
NOTE: When choosing DP mode, the Auto Adjust function is not available.
Product-Specific Problems
Specific Symptoms What You
Experience
Possible Solutions
Screen image is too
small
Image is centered on
screen, but does not
fill entire viewing area
•Check the Aspect Ratio setting in the
Display OSD.
•Reset the monitor to Factory
Settings.
Cannot adjust the
monitor with the
buttons on the front
panel
OSD does not appear
on the screen
•Turn o the monitor, unplug the
power cord, plug back, and then turn
on the monitor.
•Check whether the OSD menu is
locked. If yes, press and hold the
button beside the Power button
for 10 seconds to unlock (for more
information, see Lock).
No Input Signal when
user controls are
pressed
No picture, the LED
light is white. When
you press “up”, “down”
or “Menu” key, the
message “ No input
signal” will appear.
•Check the signal source. Ensure the
computer is not in the power saving
mode by moving the mouse or
pressing any key on the keyboard.
•Check whether the signal cable is
plugged in properly. Re-plug the
signal cable if necessary.
•Reset the computer or video player.
The picture does not
fill the entire screen
The picture cannot fill
the height or width of
the screen
•Due to dierent video formats (aspect
ratio) of DVDs, the monitor may
display in full screen.
•Run the built-in diagnostics.

Dell E1916H Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.3 x 0.3 mm
Aspect ratio	16:9
Backlight type	W-LED
Display surface	Matt
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Display technology	LED
Viewable size diagonal	470.1 mm
Viewing angle, vertical	65 °
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	90 °
Display brightness (typical)	220 cd/m²
Supported graphics resolutions	1366 x 768
On/off switch	Yes
HDCP	-
HDMI ports quantity	0
Certification	CECP, TCO
Product color	Black
Market positioning	Business
LED indicators	Power
Panel mounting interface	100 x 100 mm
Input current	1 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	17 W
Power consumption (standby)	0.3 W
Power consumption (typical)	14 W
Power consumption (PowerSave)	10.4 W
Sustainability certificates	EPEAT Silver, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12191 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package weight	3600 g
Cables included	AC, DisplayPort

Weight and Dimensions

Depth (with stand)	167 mm
Height (with stand)	359 mm
Depth (without stand)	51.5 mm
Width (without stand)	445.4 mm
Height (without stand)	266 mm
Weight (without stand)	2260 g
