About Your Monitor 21
LCD Monitor Quality & Pixel Policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more
pixels to become fixed in an unchanging state. The visible result is a fixed pixel that
appears as an extremely tiny dark or bright discolored spot. When the pixel remains
permanently lit, it is known as a “bright dot.” When the pixel remains black, it is known
as a “dark dot.”
In almost every case, these fixed pixels are hard to see and do not detract from display
quality or usability. A display with 1 to 5 fixed pixels is considered normal and within
competitive standards. For more information, see Dell Support site at:
http://www.dell.com/support/monitors.
Maintenance Guidelines
Caring for Your Monitor
CAUTION: Read and follow the safety instructions before cleaning the
monitor.
CAUTION: Before cleaning the monitor, unplug the monitor power
cable from the electrical outlet.
For best practices, follow the instructions in the list below while unpacking, cleaning, or
handling your monitor:
• To clean your antistatic screen, slightly dampen a soft, clean cloth with water. If
possible, use a special screen-cleaning tissue or solution suitable for the antistatic
coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or compressed
air.
• Use a slightly dampened, warm cloth to clean the plastics. Avoid using detergent of
any kind as some detergents leave a milky film on the plastics.
• If you notice a white powder when you unpack your monitor, wipe it off with a
cloth. This white powder occurs during the shipping of the monitor.
• Handle your monitor with care as a darker-colored monitor may scratch and show
white scuff marks more than a lighter-colored monitor.
• To help maintain the best image quality on your monitor, use a dynamically
changing screen saver and power off your monitor when not in use.

Questions and Answers:

Dell E1916H Specifications

General IconGeneral
3DNo
Panel typeTN
Pixel pitch0.3 x 0.3 mm
Aspect ratio16:9
Backlight typeW-LED
Display surfaceMatt
Display diagonal18.5 \
Display resolution1366 x 768 pixels
Display technologyLED
Viewable size diagonal470.1 mm
Viewing angle, vertical65 °
Contrast ratio (typical)600:1
Display number of colors16.78 million colors
Viewing angle, horizontal90 °
Display brightness (typical)220 cd/m²
Supported graphics resolutions1366 x 768
On/off switchYes
HDCP-
HDMI ports quantity0
CertificationCECP, TCO
Product colorBlack
Market positioningBusiness
LED indicatorsPower
Panel mounting interface100 x 100 mm
Input current1 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)17 W
Power consumption (standby)0.3 W
Power consumption (typical)14 W
Power consumption (PowerSave)10.4 W
Sustainability certificatesEPEAT Silver, ENERGY STAR
Operating altitude0 - 5000 m
Non-operating altitude0 - 12191 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
Package weight3600 g
Cables includedAC, DisplayPort
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)167 mm
Height (with stand)359 mm
Depth (without stand)51.5 mm
Width (without stand)445.4 mm
Height (without stand)266 mm
Weight (without stand)2260 g
