Steps
1. Lift the latch and disconnect the touchpad cable from the system board.
2. Lift the latch and disconnect the touchpad cable from the touchpad.
3. Lift the touchpad cable off the palm-rest and keyboard assembly.
4. Remove the five screws (M1.6x2.5) and the four screws (M2x2) that secure the touchpad to the palm-rest and keyboard
assembly.
5. Lift the touchpad off the palm-rest and keyboard assembly.
Installing the touchpad
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following images indicate the location of the touchpad and provides a visual representation of the installation procedure.
58
Removing and installing Field Replaceable Units (FRUs)

Dell Inspiron 14 7430 2-in-1 Specifications

General

Graphics	Intel Iris Xe Graphics
Weight	1.57 kg (3.46 lbs)
Audio	Stereo speakers with Waves MaxxAudio Pro
Color Options	Platinum Silver
Processor	13th Gen Intel Core i5-1335U or i7-1355U
Display	14.0-inch FHD+ (1920 x 1200) Touchscreen
Memory	8GB LPDDR5 RAM
Storage	512GB PCIe NVMe SSD
Operating System	Windows 11 Home
Battery	4-cell, 54Wh Lithium-ion
Wireless	Wi-Fi 6E and Bluetooth 5.2
Ports	1 x HDMI 1.4 port
