Dell Inspiron 1420 User Manual

Using Multimedia 73
1 Turn off the computer and the TV and/or audio device that you want to
connect.
2 Connect the component video adapter to the S-video TV-out connector on
the computer.
3 Plug all three ends of the component video cable into the component
video-output connectors on the component video adapter. Make sure that
the red, green, and blue colors of the cable match the corresponding
adapter ports.
4 Plug all three connectors from the other end of the component video cable
into the component video-input connectors on the TV. Make sure that the
red, green, and blue colors of the cable match the colors of the TV input
connectors.
5 Plug one end of the S/PDIF digital audio cable into the S/PDIF audio
connector on the component video adapter.
1 component video adapter 2 component video-output connectors
3 component video cable
1 component video adapter 2 S/PDIF digital audio cable
31
2
2
1

Dell Inspiron 1420 Specifications

General

Processor	Intel Core 2 Duo
Display	14.1 inch WXGA (1280 x 800) display with TrueLife
RAM	Up to 4GB DDR2
Storage	Up to 250GB SATA Hard Drive
Graphics	Intel GMA X3100 or NVIDIA GeForce 8400M GS
Operating System	Windows Vista
Optical Drive	8X DVD+/-RW Drive
Wireless	Dell Wireless 1395 802.11g
Battery	6-cell Lithium Ion
Battery Life	Up to 3 hours
Ports	4 USB 2.0, VGA, Ethernet, Headphone, Microphone, ExpressCard slot
