Dell Latitude 3189 User Manual

System Conguration screen options
Option Description
Drives Allows you to congure the SATA drives on board.
• SATA-0 enabled by default
• eMMC (System Default)
USB Conguration
This is an optional feature.
This eld congures the integrated USB controller. If Boot Support is enabled, the system is allowed to boot any
type of USB Mass Storage Devices—HDD, memory key, oppy.
If USB port is enabled, device attached to this port is enabled and available for OS.
If USB port is disabled, the OS cannot see any device attached to this port.
The options are:
• Enable Boot Support—enabled by default
• Enable External USB Port—enabled by default
NOTE: USB keyboard and mouse always work in the BIOS setup irrespective of these settings.
USB PowerShare This eld congures the USB PowerShare feature behavior. This option allows you to charge external devices using
the stored system battery power through the USB PowerShare port. This option is disabled by default.
Audio This eld enables or disables the integrated audio controller. By default, the Enable Audio option is selected. The
options are:
• Enable Microphone—by default enable
• Enable Internal Speaker—(default enable)
Debug Memory
Frequency
Conguration
Allows you to enable or disable the following devices:
• Memory Frequency 1866
• Memory Frequency 1600 (default enable)
Miscellaneous
Devices
Allows you to enable or disable the following devices:
• Front-Facing Webcam (default enable)
• World-Facing Camera (default enable)
• Secure Digital (SD) card—enabled
• Secure Digital (SD) card boot
• Secure Digital (SD) card read-only-mode
Video screen options
Option
Description
LCD Brightness Allows you to set the display brightness depending up on the power source—On Battery and On AC. The LCD
brightness is independent for battery and AC adapter. It can be set using the slider.
NOTE: The video setting is visible only when a video card is installed into the system.
52 System setup options

Dell Latitude 3189 Specifications

General

Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Black
Market positioning	Educational
Tjunction	105 °C
Processor cache	2 MB
Processor cores	4
Processor model	N4200
System bus rate	- GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium Processor N4000 Series for Mobile
Processor socket	BGA 1296
Processor codename	Apollo Lake
Processor frequency	1.1 GHz
Processor cache type	L2
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	2.5 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2, 1x2+2x1
Thermal Design Power (TDP)	6 W
Scenario Design Power (SDP)	4 W
Maximum number of PCI Express lanes	6
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
SSD form factor	M.2
Card reader integrated	Yes
Total storage capacity	128 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Display diagonal	11.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Number of execution units	18
On-board graphics card ID	0x5A84
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 505
Maximum on-board graphics card memory	8 GB
On-board graphics card base frequency	200 MHz
On-board graphics card burst frequency	750 MHz
Audio chip	Realtek ALC3246
Speaker power	2 W
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
Rear camera resolution (numeric)	1 MP
Front camera resolution (numeric)	5 MP
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Docking connector	-
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Trial software	McAfee, Microsoft Office
Battery capacity	42 Wh
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Cable lock slot type	Noble
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Processor ARK ID	95592
Processor package size	24 x 31 mm
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	207.9 mm
Width	303.8 mm
Height	20.75 mm
Weight	1474.9 g
