Dell Latitude 3189 User Manual

7 Click Get drivers and click View All Drivers.
The Drivers and Downloads page opens.
8 On the Drivers and Downloads screen, under the Operating System drop-down list, select BIOS.
9 Identify the latest BIOS le and click Download File.
You can also analyze which drivers need an update. To do this for your product, click Analyze System for Updates and follow the
instructions on the screen.
10 Select your preferred download method in the Please select your download method below window, click Download File.
The File Download window appears.
11 Click Save to save the le on your computer.
12 Click Run to install the updated BIOS settings on your computer.
Follow the instructions on the screen.
NOTE: It is recommended not to update the BIOS version for more than 3 revisions. For example: If you want to update the BIOS
from 1.0 to 7.0, then install version 4.0 rst and then install version 7.0.
System and setup password
You can create a system password and a setup password to secure your computer.
Password type Description
System password Password that you must enter to log on to your system.
Setup password Password that you must enter to access and make changes to the BIOS settings of your computer.
CAUTION: The password features provide a basic level of security for the data on your computer.
CAUTION: Anyone can access the data stored on your computer if it is not locked and left unattended.
NOTE: Your computer is shipped with the system and setup password feature disabled.
Assigning a system password and setup password
You can assign a new System Password only when the status is in Not Set.
NOTE
: If the password jumper is disabled, the existing System Password and Setup Password are deleted and you need not
provide the system password to log on to the computer.
To enter the system setup, press F2 immediately after a power-on or re-boot.
1 In the System BIOS or System Setup screen, select Security and press Enter.
The Security screen is displayed.
2 Select System Password and create a password in the Enter the new password eld.
Use the following guidelines to assign the system password:
• A password can have up to 32 characters.
• The password can contain the numbers 0 through 9.
• Only lower case letters are valid, upper case letters are not allowed.
• Only the following special characters are allowed: space, (”), (+), (,), (-), (.), (/), (;), ([), (\), (]), (`).
3 Type the system password that you entered earlier in the Conrm new password eld and click OK.
4 Press Esc and a message prompts you to save the changes.
5 Press Y to save the changes.
The computer reboots.
System setup options
59

Dell Latitude 3189 Specifications

General

Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Black
Market positioning	Educational
Tjunction	105 °C
Processor cache	2 MB
Processor cores	4
Processor model	N4200
System bus rate	- GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium Processor N4000 Series for Mobile
Processor socket	BGA 1296
Processor codename	Apollo Lake
Processor frequency	1.1 GHz
Processor cache type	L2
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	2.5 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2, 1x2+2x1
Thermal Design Power (TDP)	6 W
Scenario Design Power (SDP)	4 W
Maximum number of PCI Express lanes	6
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
SSD form factor	M.2
Card reader integrated	Yes
Total storage capacity	128 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Display diagonal	11.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Number of execution units	18
On-board graphics card ID	0x5A84
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 505
Maximum on-board graphics card memory	8 GB
On-board graphics card base frequency	200 MHz
On-board graphics card burst frequency	750 MHz
Audio chip	Realtek ALC3246
Speaker power	2 W
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
Rear camera resolution (numeric)	1 MP
Front camera resolution (numeric)	5 MP
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Docking connector	-
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Trial software	McAfee, Microsoft Office
Battery capacity	42 Wh
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Cable lock slot type	Noble
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Processor ARK ID	95592
Processor package size	24 x 31 mm
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	207.9 mm
Width	303.8 mm
Height	20.75 mm
Weight	1474.9 g
