Dell Latitude 3490 User Manual

Webcam specifications
This topic lists out the detailed camera specifications.
Easy Remote Collaboration:
● Video conference online with a built-in camera.
● Touch configurations include Infra-Red camera which is dedicated to support Windows Hello feature but also functions as
normal RGB camera.
Table 4. Webcam specifications
Webcam Features HD VGA Infra-Red
Mode RGB Infra-Red RGB
Camera Type HD fixed focus VGA fixed focus HD fixed focus
Sensor Type CMOS sensor
technology
CMOS sensor
technology
CMOS sensor technology
Resolution: Motion Video Up to 1280 x 720 (0.92
MP)
Up to 640 X 480
(0.3 MP)
Up to 1280 x 720 (0.92 MP)
Resolution: Still Image Up to 1280 x 720
(0.92MP)
Up to 640 X 480
(0.3MP)
Up to 1280 x 720 (0.92MP)
Imaging Rate Up to 30 frames per
second
Up to 30 frames per
second
Up to 30 frames per second
Wired communications
Table 5. Realtek RTL8111-HSD Gigabit Ethernet Controller
Network Adapter (NIC)
Realtek RTL8111-HSD Gigabit Ethernet Controller Integrated on system board
External connector type RJ-45
Data Rates 10/100/1000 Mbps
Controller bus architecture PCI-e V1.1x1
Power consumption (full operation per data rate connection
speed)
1000 Mbps: 828 mW
100 Mbps: 441.77 mW
10 Mbps: 387.94 mW
Power consumption (standby operation)
WOL Disabled: 10mW (Disabled using driver)
No Link (w/ WOL): 51.89 mW (cable Disconnect)
10 Mbps Idle (w/ WOL): 68 mW
100 Mbps Idle (w/ WOL): 176 mW
IEEE standards compliance 802.3, 802.3ab, 802.3u, 802.az
Boot ROM Support Support boot from PXE option ROM
Network Transfer Rate
Full duplex at 10, 100, or 1000 Mbps and
Half duplex at 10 or 100 Mbps.
Operating Temp/Storage Temp 0C to70C/-55C to 125C
Operating Humidity 30°C / 60% RH (Level 3)
Operating System Driver support Linux, Win7, Win10
Technical specifications 61

Dell Latitude 3490 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Business
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
AC adapter included	Yes
HDD size	2.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	No
Total storage capacity	500 GB
Compatible memory cards	SD, SDHC, SDXC
Number of HDDs installed	1
On-board graphics card ID	0x5917
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 620
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Audio chip	Realtek ALC3246
Audio system	MaxxAudio Pro
Speaker power	2 W
Speakers manufacturer	Waves
Number of built-in speakers	2
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
Front camera signal format	720p
Front camera resolution (numeric)	0.92 MP
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Qualcomm QCA61x4A
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
DisplayPorts quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pointing device	Touchpad
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.34 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Pixel pitch	0.226 x 0.226 mm
Pixel density	112 ppi
Display surface	Matt
Display diagonal	14 \
Display brightness	220 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
Bus type	OPI
Stepping	Y0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1356
Processor threads	8
Processor codename	Kaby Lake R
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	1.8 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Operating system language	ENG, ESP, FRE
Battery capacity	56 Wh
Processor code	SR3LA
Processor ARK ID	124967
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	241.9 mm
Width	339 mm
Height	21 mm
Weight	1780 g
