Dell Latitude 7320 User Manual

Dell SupportAssist Pre-boot System Performance
Check diagnostics
About this task
SupportAssist diagnostics (also known as system diagnostics) performs a complete check of your hardware. The Dell
SupportAssist Pre-boot System Performance Check diagnostics is embedded with the BIOS and is launched by the BIOS
internally. The embedded system diagnostics provides a set of options for particular devices or device groups allowing you to:
● Run tests automatically or in an interactive mode
● Repeat tests
● Display or save test results
● Run thorough tests to introduce additional test options to provide extra information about the failed device(s)
● View status messages that inform you if tests are completed successfully
● View error messages that inform you of problems encountered during testing
NOTE: Some tests for specific devices require user interaction. Always ensure that you are present at the computer
terminal when the diagnostic tests are performed.
For more information, see https://www.dell.com/support/kbdoc/000180971.
Running the SupportAssist Pre-Boot System Performance Check
Steps
1. Turn on your computer.
2. As the computer boots, press the F12 key as the Dell logo appears.
3. On the boot menu screen, select the Diagnostics option.
4. Click the arrow at the bottom left corner.
Diagnostics front page is displayed.
5. Click the arrow in the lower-right corner to go to the page listing.
The items detected are listed.
6. To run a diagnostic test on a specific device, press Esc and click Yes to stop the diagnostic test.
7. Select the device from the left pane and click Run Tests.
8. If there are any issues, error codes are displayed.
Note the error code and validation number and contact Dell.
Built-in self-test (BIST)
M-BIST
M-BIST (Built In Self-Test) is the system board's built-in self-test diagnostics tool that improves the diagnostics accuracy of
system board embedded controller (EC) failures.
NOTE: M-BIST can be manually initiated before POST (Power On Self Test).
How to run M-BIST
NOTE: M-BIST must be initiated on the system from a power-off state either connected to AC power or with battery only.
1. Press and hold both the M key on the keyboard and the power button to initiate M-BIST.
2. With both the M key and the power button held down, the battery indicator LED may exhibit two states:
a. OFF: No fault detected with the system board
b. AMBER: Indicates a problem with the system board
3. If there is a failure with the system board, the battery status LED will flash one of the following error codes for 30 seconds:
Troubleshooting
77

Dell Latitude 7320 Specifications

General

Processor cores	2
Processor model	i3-1110G4
Processor family	Intel® Core™ i3
Processor frequency	- GHz
Processor manufacturer	Intel
Processor boost frequency	3.9 GHz
Configurable TDP-down frequency	1.5 GHz
Memory clock speed	4267 MHz
Internal memory type	LPDDR4x-SDRAM
Maximum internal memory	4 GB
Panel type	WVA
Pixel density	177 ppi
Display diagonal	13 \
Display brightness	500 cd/m²
Display resolution	1920 x 1280 pixels
Native aspect ratio	3:2
Anti-reflective coating	Yes
Speaker power	2.5 W
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Wi-Fi data rate (max)	2400 Mbit/s
Mobile network connection	No
SSD interface	M.2, PCI Express
Storage media	SSD
Internal storage capacity	128 GB
Platform	Windows
Operating system architecture	64-bit
Rear camera type	Single camera
Video capturing speed	30 fps
Rear camera resolution	1920 x 1080 pixels
Rear camera resolution (numeric)	8 MP
Cables included	AC
Battery voltage	8.9 V
Battery capacity	4494 mAh
Battery life (max)	- h
Battery recharge time	4 h
Device type	Tablet PC
Form factor	Slate
Product color	Gray
Housing material	Aluminum
Graphics card	Iris Xe Graphics

Weight and Dimensions

Depth	207.9 mm
Width	288.42 mm
Height	8.44 mm
Weight	789 g
