Dell M410HD User Manual

Using Your Projector 15
3 To power off the projector quickly, press the Power button and hold for 1
second while the projector’s cooling fans are still running.
NOTE: Before you turn on the projector again, wait for 60 seconds to allow the
internal temperature to stabilize.
4 Disconnect the power cord from the electrical outlet and the projector.
Adjusting the Projected Image
Raising the Projector Height
1 Press the Elevator button.
2 Raise the projector to the desired display angle, and then release the button to
lock the elevator foot into position.
3 Use the tilt adjustment wheel to fine-tune the display angle.
Lowering the Projector Height
1 Press the Elevator button.
2 Lower the projector, and then release the button to lock the elevator foot into
position.
1 Elevator button
2 Elevator foot (Angle of tilt: 0 to 9.5 degree)
3 Tilt adjustment wheel
3 3
1
2

Dell M410HD Specifications

General

Projection distance	1 - 12 m
Projection technology	DLP
Contrast ratio (typical)	2100:1
Projector native resolution	WXGA (1280x800)
Lamp power	165 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
Audio input	1
Dimensions (WxDxH)	205 x 155 x 75.9 mm
Power requirements	AC 100-240 50-60Hz
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	1 W
AC (power) in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	210 W
Storage temperature (T-T)	0 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	80 - 90 %

Weight and Dimensions

Weight	1180 g
