Dell Mobile M115HD User Manual

M
1
Installing the Remote Control Battery (Optional)
Remove the battery holder by holding
down the side release firmly and pulling
out the battery holder.
2 Insert a CR2032 coin cell battery and
align the polarity correctly according to
the marking in the battery holder.
NOTE: When you use the remote control
for the first time, there is a plastic sheet
between the battery and its contact.
Remove the sheet before use.
3 Replace the battery holder.
3
V
O
L
T
S
CR2032
3
V
O
L
T
S
CR2032
3
V
O
L
T
S
CR2025
Using Your Projector 24

Dell Mobile M115HD Specifications

General

Display Type	DLP
Resolution	WXGA (1280 x 800)
Aspect Ratio	16:10
Brightness	450 ANSI Lumens
Contrast Ratio	10, 000:1
Weight	0.8 lbs (360g)
Inputs	HDMI, USB
Built-in Speaker	Yes
Screen Size	30" - 80"
Projection Distance	0.97m - 2.58m
