Dell OptiPlex 580 User Manual

OptiPlex580TechnicalGuidebook Page16
Graphics/Video Controller
NOTE: MT supports full height card, DT supports low profile card or full height card with optional riser. SFF supports low profile
card.
MT DT SFF
Integrated ATI Radeon HD 4200 Graphics
1
Integrated on system board with specific processors
Enhanced Graphic/Video Options
256MB AMD RADEON HD 3450 Graphics, dual DVI or VGA and TV Out Optional full height or low profile card
256MB NVIDIA 9300GE Graphics, dual DVI or VGA and TV Out Optional full height or low profile card
256MB AMD RADEON HD 3470 Graphics, dual DP Optional full height or low profile card
512MB AMD RADEON HD4550 Graphics, dual DP Optional full height or low profile card
512MB NVIDIA NVS420 Graphics, quad DP or DVI NA NA Low Profile
1
Up to 1.7 GB of system memory may be allocated to support integrated graphics, depending on operating system, system memory size and
other factors.
External Ports/Connectors
NOTE: MT supports full height cards, DT supports low profile cards or full height cards with optional riser. SFF supports low
profile cards.
See chassis diagrams section for port/connector locations
MT DT SFF
USB 2.0 (includes two internal on MT, DT and SFF) 8 8 8
Serial One rear
PS/2 NA
eSATA One rear
Parallel NA
Network Connector (RJ-45) One rear
Video: (enabled with specific processors)
VGA One rear
Display Port One rear
Audio:
Microphone-in One minijack front
Headphone One minijack front
Stereo line-in/micropone One minijack rear
Speakers line out One minijack rear

Dell OptiPlex 580 Specifications

General

Chipset	AMD 785G
Optical Drive	DVD-ROM or DVD+/-RW
Audio	Integrated High Definition Audio
Memory	Up to 8GB DDR3
Graphics	ATI Radeon HD 4200 integrated graphics
Operating System	Windows 7, Ubuntu
Networking	Integrated Broadcom 5761 Ethernet LAN 10/100/1000
Ports	USB 2.0, VGA, DisplayPort, serial
Power Supply	255W
Form Factor	Mini Tower, Desktop
