Dell OptiPlex 580 User Manual

OptiPlex580TechnicalGuidebook Page42
Recommended Enclosure Do not install your computer in an enclosure that does not allow airflow. This restricts the airflow
and impacts your computer’s performance, possibly causing it to overheat.
Open Desk Minimum Clearance If your computer is installed in a corner, on a desk, or under a desk, leave at least 5.1 cm (2 in.)
clearance from the back of the computer to the wall to permit the airflow required for proper ventilation.

Dell OptiPlex 580 Specifications

General

Chipset	AMD 785G
Optical Drive	DVD-ROM or DVD+/-RW
Audio	Integrated High Definition Audio
Memory	Up to 8GB DDR3
Graphics	ATI Radeon HD 4200 integrated graphics
Operating System	Windows 7, Ubuntu
Networking	Integrated Broadcom 5761 Ethernet LAN 10/100/1000
Ports	USB 2.0, VGA, DisplayPort, serial
Power Supply	255W
Form Factor	Mini Tower, Desktop
