Dell OptiPlex 7460 User Manual

NOTE: Ensure that the computer and all attached devices are turned o. If your computer and attached devices did not
automatically turn o when you shut down your operating system, press and hold the power button for about 6 seconds to
turn them o.
Before working inside your computer
1 Ensure that your work surface is at and clean to prevent the computer cover from being scratched.
2 Turn o your computer.
3 If the computer is connected to a docking device (docked), undock it.
4 Disconnect all network cables from the computer (if available).
CAUTION: If your computer has an RJ45 port, disconnect the network cable by rst unplugging the cable from your
computer.
5 Disconnect your computer and all attached devices from their electrical outlets.
6 Open the display.
7 Press and hold the power button for few seconds, to ground the system board.
CAUTION: To guard against electrical shock unplug your computer from the electrical outlet before performing Step # 8.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an
unpainted metal surface at the same time as touching a connector on the back of the computer.
8 Remove any installed ExpressCards or Smart Cards from the appropriate slots.
After working inside your computer
After you complete any replacement procedure, ensure that you connect external devices, cards, and cables before turning on your
computer.
CAUTION
: To avoid damage to the computer, use only the battery designed for this particular Dell computer. Do not use batteries
designed for other Dell computers.
1 Connect any external devices, such as a port replicator or media base, and replace any cards, such as an ExpressCard.
2 Connect any telephone or network cables to your computer.
CAUTION
: To connect a network cable, rst plug the cable into the network device and then plug it into the
computer.
3 Connect your computer and all attached devices to their electrical outlets.
4 Turn on your computer.
Working on your computer
7

Dell OptiPlex 7460 Specifications

General

Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
LED backlight	Yes
Display surface	Matt
Display diagonal	24 \
Display brightness	250 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI3
Tjunction	100 °C
Processor code	SR3QS
Processor cache	12 MB
Processor cores	6
Processor model	i7-8700
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-8700 Desktop Series
Processor socket	LGA 1151 (Socket H4)
Processor threads	12
Processor codename	Coffee Lake
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	65 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Maximum internal memory supported by processor	64 GB
Number of execution units	24
On-board graphics card ID	0x3E92
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 630
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
Operating system language	ENG, ESP, FRE
Memory slots	2
Internal memory	8 GB
Memory slots type	SO-DIMM
Memory form factor	DIMM/SO-DIMM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
HDD size	2.5 \
HDD speed	7200 RPM
Storage media	HDD
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Antenna type	2x2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product type	All-in-One PC
HDMI version	1.4/2.0
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Product color	Black, Grey
Scalability	1S
Processor ARK ID	126686
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2015C
Intel Identity Protection Technology version	1.00
AC adapter frequency	47/63 Hz
AC adapter input voltage	90 - 264 V
Keyboard language	-
Privacy type	Pop-up
Total megapixels	2 MP
Camera signal format	1080p
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	- mm
Width (with stand)	540.2 mm
Weight (with stand)	- g
Depth (without stand)	52.8 mm
Height (without stand)	344 mm
Weight (without stand)	6040 g
