Solid Amber – The system is unable to boot to the operating system. This indicates that the power supply or another device in the system
is failing.
Blinking Amber – The system is unable to boot to the operating system. This indicates that the power supply is normal but another device
in the system is failing or not installed properly.
NOTE: To determine the device that is failing, see the light patterns .
O – System is in hibernation or turned o.
The power status light blinks amber along with beep codes indicating failures.
For example, the power status light blinks amber two times followed by a pause, and then blinks white three times followed by a pause. This
2,3 pattern continues until the computer is turned o indicating the Recovery image is not found.
The following table shows dierent light patterns and what they indicate:
Table 4. Diagnostic LED/Beep codes
LED # of Flashes Problem description Faults
2,1 Faulty system board Faulty system board
2,2 Faulty system board, power supply unit
(PSU), or cabling
Faulty system board, power supply unit (PSU), or cabling
2,3 Faulty system board, CPU, or DIMMS Faulty system board, power supply unit (PSU), or DIMMS
2,4 Faulty coin cell battery Faulty coin cell battery
2,5 BIOS Recovery AutoRecovery trigger, recovery image is not found or is
invalid
2,6 CPU CPU Error
2,7 Memory Memory SPD failure
3,3 Memory No memory detected
3,5 Memory Modules incompatible or invalid conguration
3,6 BIOS Recovery On-demand trigger, recovery image is not found
3,7 BIOS Recovery On-demand trigger, recovery image is invalid
The system may emit a series of beeps during start-up if the errors or problems cannot be displayed. The repetitive beep codes help the
user troubleshoot problems with the system.
Camera status light: Indicates whether the camera is in use.
• Solid white – Camera is in use.
• O – Camera is not in use.
LCD built in self test - BIST
All-in-One (AIO) systems supports LCD BIST similar to any other Dell systems that have BIST test implemented. It allows the user to isolate
the LCD during troubleshooting to determine which sub-system is at fault. The main dierence is the lack of an integrated keyboard scan
controller in the AIO. When BIST is initiated, an internal generated pattern from the LCD will be emitted for user's observation. This pattern
will go by sequence through this pattern, Red- Green-Blue-White-Blue where each pattern is emitted for 2 to 3 seconds.
The following images displays the pattern of the colors on the LCD:
Standard display
Troubleshooting your computer
97

Dell OptiPlex 7460 Specifications

General

Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
LED backlight	Yes
Display surface	Matt
Display diagonal	24 \
Display brightness	250 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI3
Tjunction	100 °C
Processor code	SR3QS
Processor cache	12 MB
Processor cores	6
Processor model	i7-8700
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-8700 Desktop Series
Processor socket	LGA 1151 (Socket H4)
Processor threads	12
Processor codename	Coffee Lake
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	65 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Maximum internal memory supported by processor	64 GB
Number of execution units	24
On-board graphics card ID	0x3E92
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 630
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
Operating system language	ENG, ESP, FRE
Memory slots	2
Internal memory	8 GB
Memory slots type	SO-DIMM
Memory form factor	DIMM/SO-DIMM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
HDD size	2.5 \
HDD speed	7200 RPM
Storage media	HDD
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Antenna type	2x2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product type	All-in-One PC
HDMI version	1.4/2.0
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Product color	Black, Grey
Scalability	1S
Processor ARK ID	126686
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2015C
Intel Identity Protection Technology version	1.00
AC adapter frequency	47/63 Hz
AC adapter input voltage	90 - 264 V
Keyboard language	-
Privacy type	Pop-up
Total megapixels	2 MP
Camera signal format	1080p
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	- mm
Width (with stand)	540.2 mm
Weight (with stand)	- g
Depth (without stand)	52.8 mm
Height (without stand)	344 mm
Weight (without stand)	6040 g
