2. Slide the M.2 2280 solid-state drive into the solid-state drive slot
3. Slide the M.2 thermal shield back in place and replace the screw (M2x3) that secures it to the system board.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Wireless card
Removing the wireless card
Prerequisites
1. Follow the procedure in Before working inside your computer.
NOTE: Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your
computer.
2. Remove the base cover.
About this task
The following image(s) indicate the location of the wireless card and provides a visual representation of the removal procedure.
24
Removing and installing components
