Wireless card
Removing the wireless card
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
NOTE: Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your
computer.
About this task
The following image(s) indicate the location of the wireless card and provides a visual representation of the removal procedure.
Steps
1. Remove the screw (M2x3) that secures the wireless-card bracket to the wireless card and palm-rest and keyboard
assembly.
2. Lift the wireless-card bracket off the wireless card.
3. Disconnect the antenna cables from the wireless card.
4. Slide and remove the wireless card off the wireless-card slot on the system board.
20
Removing and installing components
