Table 12. Power adapter specifications (continued)
Features Specifications
Output current 3.34 A (continuous)
Rated output voltage 19.5 VDC
Temperature range (Operating) 0 °C to 40 °C (32 °F to 104 °F )
Temperature range (Non-Operating) -40º to 70º C (-40º to 158º F)
Dimensions and weight
Table 13. Dimensions and weight
Dimensions Vectors
Height
● Front height - 0.817 inch (20.75 mm)
● Back height - 0.817 inch (20.75 mm)
Width 11.94 inch (303.3 mm)
Depth 8.11 inch (206 mm)
Weight Starting 2.79 lbs (1.27 kg)
Environmental specifications
Temperature
Specifications
Operating 0°C to 35°C (32°F to 95°F)
Storage –40°C to 65°C (–40°F to 149°F)
Relative
humidity
(maximum)
Specifications
Operating 10 % to 90 % (non condensing)
Storage 5 % to 95 % (non condensing)
Altitude
(maximum)
Specifications
Operating 0 m to 3048 m (0 ft to 10,000 ft)
Non-operating 0 m to 10,668 m (0 ft to 35,000 ft)
Airborne
contaminant level
G1 as defined by ISA-71.04–1985
Support policy
For more information on support policy, see the knowledge base articles 000181418, 000043920 and 000046323.
22
Technical specifications
