Dell PowerEdge EMT User Manual

72 Installing System Components
Figure 3-18. Removing and Installing an Expansion Card
7 Close the card retention door to secure the remaining card(s) in the
system. See Figure 3-18.
8 Close the system. See "Closing the System" on page 47.
9 Reconnect the system to the electrical outlet, and turn on the system and
attached peripherals.
10 Remove the card’s device driver from the operating system.
1 expansion card 2 alignment guide
3 card retention door 4 release tab
2
4
3
1
book.book Page 72 Wednesday, June 24, 2009 8:21 AM

Dell PowerEdge EMT Specifications

General

Brand	Dell
Model	PowerEdge EMT
Category	Server
Language	English
