Dell ST2220T User Manual

Back View
Side View
Bottom View
1
Preset Modes select
2
Brightness/Contrast select
3
OSD menu select
4
EXIT
5
Power button (with light indicator)
Back view
Back View with monitor stand
Label
Description
Use
1
Barcode serial number label
To contact Dell for technical support.
2
Regulatory rating label
Lists the regulatory approvals.
3
Cable holder
To organize cables by placing them through the holder.
4
USB downstream port
To connect the USB cable.
5
Security lock slot
To help secure your monitor.
Leftview
Right view

Dell ST2220T Specifications

General

Pixel pitch	0.248 x 0.248 mm
Screen shape	Flat
Response time	8 ms
Display diagonal	21.5 \
Display brightness	250 cd/m²
Display technology	LCD
Touchscreen technology	Optical imaging
Contrast ratio (dynamic)	50000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	54.6 cm
Certification	EPEAT Silver
Product color	Black
Ethernet LAN (RJ-45) ports	0
Display viewable area (HxV)	475.2 x 267.3 mm
Dimensions (W x D x H) with stand	528.1 x 58.5 x 380.1 mm
Cables included	DVI, USB, VGA
DVI-D ports quantity	1
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	28 W
Operating altitude	0 - 3658 m
Non-operating altitude	3658 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package weight	7800 g
Wall mountable	No
Panel mounting interface	No mm
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	58.5 mm
Width (with stand)	528.1 mm
Height (with stand)	380.1 mm
Weight (with stand)	6300 g
