Setting Up the Monitor | 31
Removing the Cable Cover
1
2
1.
Press the tab on the cable cover.
2.
Remove the two tabs on the bottom part of the cable cover from the groove on
the back of the monitor.
Wall Mounting (Optional)
Service Tag:1NGTQV1
Express SVC code:359 576 607 77
(Screw dimension: M4 x 10 mm).
Refer to the instructions that come with the VESA-compatible wall mounting kit.
1.
Place the monitor panel on a soft cloth or cushion on a stable, flat table.
2.
Remove the stand.
3.
Use a Phillips crosshead screwdriver to remove the four screws securing the
plastic cover.
4.
Attach the mounting bracket from the wall mounting kit to the monitor.
5.
Mount the monitor on the wall by following the instructions that comes with the
wall mounting kit.
NOTE: For use only with UL-listed wall mount bracket with minimum weight/
load bearing capacity of 4.91 kg.
