Preset Display Modes
Display Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (Horizontal/Vertical)
VESA, 720 x 400 31.5 70.0 28.3 -/+
VESA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.0 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1152 x 864 67.5 75.0 108.0 +/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1280 x 800 49.7 60.0 83.5 +/+
VESA, 1600 x 1200 75.0 60.0 162.0 +/+
VESA, 1920 x 1200 74.0 60.0 154.0 +/+
VESA, 2048 x 1280 - R 78.9 60.0 174.3 +/+
VESA, 2560 x 1600 99.5 60.0 348.5 +/+
Electrical Specifications
Video input signals
Digital DVI TMDS, 600mV for each differential line, positive polarity at 50 ohm input impedance
DP1.2/HDMI1.4 signal input support
AC input voltage/frequency/current 100 VAC to 240 VAC / 50 Hz or 60 Hz +
3 Hz / 1.8 A (Typical)
Inrush current
120 V : 30 A (Max)
240 V : 60 A (Max)
Physical Characteristics
Connector type DVI-D, white connector
DP, black connector (include DP in and DP out)
Mini DP
HDMI
USB 3.0
Signal cable type
DVI-D
Mini DP to DP
HDMI
USB 3.0
Dimensions (with stand)
