Dell UltraSharp 24 User Manual

14 | About your monitor
HBR3 2
HBR2 1
Electrical specifications
Video input signals • Digital video signal for each dierential line
Per dierential line at 100 ohm impedance
• DP/HDMI/USB Type-C signal input support
Input voltage/ frequency/current 100-240 VAC / 50 or 60 Hz ± 3 Hz / 2.1 A
(maximum)
Inrush current 120 V: 42 A (Max.)
240 V: 80 A (Max.)
Inrush current is measured at an ambient
temperature of 0°C.
Power Consumption 0.2 W (Off Mode)
1
0.2 W (Standby Mode)
1
17.2 W (On Mode)
1
186 W (Max)
2
16.16 W (Pon)
3
52.39 kWh (TEC)
3
1
As dened in EU 2019/2021 and EU 2019/2013.
2
Max brightness and contrast setting with maximum power loading on all USB ports.
3
Pon: Power consumption of On Mode as dened in Energy Star 8.0 version.
TEC: Total energy consumption in kWh as dened in Energy star 8.0 version.
This document is informational only and reects laboratory performance. Your prod-
uct may perform dierently, depending on the software, components and peripherals
you ordered and shall have no obligation to update such information. Accordingly, the
customer should not rely upon this information in making decisions about electrical
tolerances or otherwise. No warranty as to accuracy or completeness is expressed or
implied.
NOTE: This monitor is ENERGY STAR certied.
This product qualies for ENERGY STAR in the factory default settings which can be
restored by “Factory Reset” function in the OSD menu. Changing the factory default
settings or enabling other features may increase power consumption that could exceed
the ENERGY STAR specied limit.

Dell UltraSharp 24 Specifications

General

3D	No
DDC/CI	Yes
HD type	WUXGA
Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:10
Screen shape	Flat
Response time	6 ms
Backlight type	LED
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Display technology	LCD
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1200 (WUXGA)
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	75 W
Annual energy consumption	26 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	23 W
Power consumption (PowerSave)	17.8 W
Certification	TCO, FCC, NFPA 99
Product color	Black
Market positioning	Business
Cables included	AC, DisplayPort, USB
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package depth	648 mm
Package width	242.1 mm
Package height	452.9 mm
Package weight	8350 g
Package material	Corrugated cardboard, Expanded polyethylene (EPE) foam, Polyethylene (PE)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
Pallet width	1016 mm
Pallet height	1025.9 mm
Pallet length	1219.2 mm
Pallet weight	128021 g
Quantity per pallet	12 pc(s)
Quantity per pallet layer	6 pc(s)
Master (outer) case weight	8332.5 g
Harmonized System (HS) code	85285210
Number of layers per pallet	2 pc(s)
Quantity per master (outer) case	1 pc(s)
Polyethylene (PE) content per bag	79.25 g
Corrugated cardboard content per package	2312 g
Expanded polyethylene (EPE) foam content per package	8.2 g
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	205 mm
Width (with stand)	532.2 mm
Height (with stand)	402.9 mm
Weight (with stand)	6690 g
Depth (without stand)	45.7 mm
Height (without stand)	350.6 mm
Weight (without stand)	4250 g
