Dell UltraSharp 24 User Manual

16 | About your monitor
Weight without stand assembly
(For wall mount or VESA mount
considerations - no cables)
4.0 kg (8.8 lb)
Weight of stand assembly 1.7 kg (3.7 lb)
Environmental characteristics
Compliant Standards
• ENERGY STAR certified Monitor.
• EPEAT registered where applicable. EPEAT registration varies by country.
See www.epeat.net for registration status by country.
• TCO Certified Display.
• RoHS Compliant.
• BFR/PVC Free monitor (excluding external cables).
• Meets NFPA 99 leakage current requirements.
• Arsenic-Free glass and Mercury-Free for the panel only.
Temperature
Operating 0°C to 40°C (32°F to 104°F)
Non-operating –20°C to 60°C (–4°F to 140°F)
Humidity
Operating 10% to 80% (non-condensing)
Non-operating 5% to 90% (non-condensing)
Altitude
Operating 5,000 m (16,404 ft) (maximum)
Non-operating 12,192 m (40,000 ft) (maximum)
Thermal dissipation 635.0 BTU/hour (Maximum)
58.72 BTU/hour (On mode)

Dell UltraSharp 24 Specifications

General

3D	No
DDC/CI	Yes
HD type	WUXGA
Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:10
Screen shape	Flat
Response time	6 ms
Backlight type	LED
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Display technology	LCD
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1200 (WUXGA)
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	75 W
Annual energy consumption	26 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	23 W
Power consumption (PowerSave)	17.8 W
Certification	TCO, FCC, NFPA 99
Product color	Black
Market positioning	Business
Cables included	AC, DisplayPort, USB
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package depth	648 mm
Package width	242.1 mm
Package height	452.9 mm
Package weight	8350 g
Package material	Corrugated cardboard, Expanded polyethylene (EPE) foam, Polyethylene (PE)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
Pallet width	1016 mm
Pallet height	1025.9 mm
Pallet length	1219.2 mm
Pallet weight	128021 g
Quantity per pallet	12 pc(s)
Quantity per pallet layer	6 pc(s)
Master (outer) case weight	8332.5 g
Harmonized System (HS) code	85285210
Number of layers per pallet	2 pc(s)
Quantity per master (outer) case	1 pc(s)
Polyethylene (PE) content per bag	79.25 g
Corrugated cardboard content per package	2312 g
Expanded polyethylene (EPE) foam content per package	8.2 g
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	205 mm
Width (with stand)	532.2 mm
Height (with stand)	402.9 mm
Weight (with stand)	6690 g
Depth (without stand)	45.7 mm
Height (without stand)	350.6 mm
Weight (without stand)	4250 g
