DeLonghi NESPRESSO Lattissima Touch User Manual

UA
ПОШУК І УСУНЕННЯ НЕСПРАВНОСТЕЙ
Немає світлового індикатору.
➔ Перевірте мережеву вилку, напругу і запобіжник. У разі виникнення проблем, телефонуйте до Клубу
Nespresso.
Немає подачі кави, води.
➔ Резервуар для води порожній. Заповніть резервуар для води.
➔ Потрібне очищення від накипу; дивіться розділ Очищення від накипу.
Слабкий потік кави.
➔ Швидкість потоку залежить від сорту кави.
➔ Потрібне очищення від накипу; дивіться розділ Очищення від накипу.
Ніякої кави, просто ллється вода ( не зважаючи на вставлену
капсулу).
➔ У разі виникнення проблем, телефонуйте до Клубу Nespresso.
Кава недостатньо гаряча.
➔ Нагрійте чашку.
➔ Потрібне очищення від накипу; дивіться розділ Очищення від накипу.
Капсула протікає (вода в контейнері для капсул).
➔ Позиція капсули неправильна. У разі виникнення проблем, телефонуйте до Клубу Nespresso.
Нерегулярне блимання.
➔ Відправте прилад на ремонт або телефонуйте до Клубу Nespresso.
Всі кнопки одночасно блимають впродовж 10 секунд, а потім
машина автоматично вимикається.
➔ Сигнал помилки, кавомашина потребує ремонту. Ві дправте прилад на ремонт або телефонуйте до
Клубу Nespresso.
Всі 6 кнопок блимають 3 рази, а потім машина входить в режим
готовності.
➔ Резервуар для води порожній.
Видалення накипу та блимання оповіщення про очищення.
➔ Машина знаходиться в режимі меню, натисніть кнопки лате макіато і молочної пінки протягом 3
секунд, щоб вийти з режиму меню або почекайте 30 секунд для автоматичного виходу.
Сигнал видалення накипу світить помаранчевим, кнопки напоїв
доступні ( видалення накипу, рівень 1).
➔ Машина потребує видалення накипу. Очистіть від накипу машину.
Сигнал видалення накипу (видалення накипу рівень 2).
➔ Процес видалення накипу був виконаний невірно. Очистіть від накипу машину.
Оповіщення про видалення накипу блимає помаранчевим
кольором і світить кнопка теплого молока.
➔ Машина знаходиться в режимі Видалення накипу. Натисніть кнопку теплої молочної піни, щоб почати
процес видалення накипу.
Оповіщення про видалення накипу світить помаранчевим,
кнопки напоїв недоступні (видалення накипу рівень 3).
➔ Машина повністю заблокована. Очистіть від накипу машину.
Постійне свічення помаранчевого вогню.
➔ Промити систему.
Всі кнопки кави і молока блимають.
➔ Машина перегрілася, чекайте, поки машина охолоне.
➔ Прилад буде заблокований протягом приблизно 10 хвилин після очищення.
Важіль повністю не опускається.
➔ Звільність контейнер для капсул. Переконайтеся, що капсула не застрягла всередині контейнера для
капсул.
Якість молочної піни не відповідає стандарту.
➔ Використовуйте знежирене або напівзнежирене молоко, охолоджене до температури (близько 4° C).
➔ Промивайте після кожного приготування молочного напою.
➔ Видаліть накип (див. стор.188).
➔ Не використовуйте заморожене молоко.
Я не можу увійти в режим меню.
➔ Обов'язково видаліть молочник.
➔ Обов'язково натисніть кнопку лате макіато і молочної піни протягом 3 секунд.
➔ Вийміть трубку для видалення накипу.
ІІ
LATTISSIMA TOUCH
EUR,AUS,NZ: 220240 V, 50/60 Hz, 1300 W
US/CA: 120 V, 60 Hz, 1200 W
19 bar
6.5 kg
1,38 litre
500 ml
13-16 capsules
l=19,4 cm . L=33,2 cm . h=27,4 cm
Troubleshooting
Contact the Nespressso Club
For any additional information, in case of problems
or simply to seek advise, call the Nespresso Club.
Contact details of the Nespresso Club can be found
in the 'Welcome to Nespresso' folder in your
machine box or at nespresso.com
No light on display
Check the mains, plug, voltage, and fuse. In case of problems, call the Nespresso Club.
Coffee comes out very slowly.
Flow speed depends on the coffee variety.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Coffee is not hot enough.
Preheat cup.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Capsule area is leaking (water in capsule container).
Position capsule correctly. If leakages occur, call the Nespresso Club.
Irregular blinking.
Send appliance to repair or call the Nespresso Club.
No coffee, just water runs out (despite inserted capsule).
In case of problems, call the Nespresso Club.
Lever cannot be closed completely
Empty capsule container. Make sure that no capsule is blocked inside the capsule container.
Quality of milk froth is not up to standard
1) For a perfect milk froth, use skimmed or semi-skimmed milk at refrigerator temperature (about 4° C)
2) Rinse after each milk based preparation. Place a recipient under milk outlet, rotate the milk
regulator knob until “CLEAN” position.
3) Every two days, disassemble the R. C. S. and clean all components in the upper level of a
dishwasher
Warranty
Delonghi warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. During this period, Delonghi will either repair or
replace, at its discretion, any defective product at no charge to the owner. Replacement products or repaired parts will be guaranteed for only the unexpired portion of the original
warranty or six months, whichever is greater. This limited warranty does not apply to any defect resulting from accident, misuse, improper maintenance, or normal wear and tear. Any
defect resulting from the usage of non genuine Nespresso capsules will not be covered by this warranty. Except to the extent allowed by applicable law, the terms of this limited warranty
do not exclude, restrict
or modify, and are in addition to, the mandatory statutory rights applicable to the sale of the product to you. If you believe your product is defective, contact Nespresso for instructions on
where to send or bring it for repair. Please visit our website at nespresso.com to discover more about Nespresso
Specifications
P
max
Once the rinsing process is finished, the
machine switches off. Clean the machine
using a damp cloth. You have now finished
descaling the machine.
9
10
11 12
Rinsing process Rinse and fill water with
fresh potable water up to MAX level.
Rinsing process Place one container of
minimum 1 litre under both the coffee
outlet and the hot water spout.
PRESS to confirm.
The rinsing cycle continues trough the coffee
outlet, hot water spout and drip tray until the
water tank is empty.
Water hardness setting
1
programmed buttons blinks 3 times: water hardness is set
i
1”
2 3 4
1
2
3
4
5
Place the water hardness sticker under
water for 1 second.
The number of red squares indicates
the water harness level.
Set the value accordinglyEnter the menu, browse the options and select
WATER HARDNESS.
You will be guided to set the value.
Follow machine display instructions.
max
max
Kg
11 12
EUR, AUS, NZ: 220-240 ,
50/60 , 1400  /
EUR,AUS,NZ: 220240 V, 50/60 Hz, 1300 W
US/CA: 120 V, 60 Hz, 1200 W
19 bar
6.5 kg
1,38 litre
500 ml
13-16 capsules
l=19,4 cm . L=33,2 cm . h=27,4 cm
Troubleshooting
Contact the Nespressso Club
For any additional information, in case of problems
or simply to seek advise, call the Nespresso Club.
Contact details of the Nespresso Club can be found
in the 'Welcome to Nespresso' folder in your
machine box or at nespresso.com
No light on display
Check the mains, plug, voltage, and fuse. In case of problems, call the Nespresso Club.
Coffee comes out very slowly.
Flow speed depends on the coffee variety.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Coffee is not hot enough.
Preheat cup.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Capsule area is leaking (water in capsule container).
Position capsule correctly. If leakages occur, call the Nespresso Club.
Irregular blinking.
Send appliance to repair or call the Nespresso Club.
No coffee, just water runs out (despite inserted capsule).
In case of problems, call the Nespresso Club.
Lever cannot be closed completely
Empty capsule container. Make sure that no capsule is blocked inside the capsule container.
Quality of milk froth is not up to standard
1) For a perfect milk froth, use skimmed or semi-skimmed milk at refrigerator temperature (about 4° C)
2) Rinse after each milk based preparation. Place a recipient under milk outlet, rotate the milk
regulator knob until “CLEAN” position.
3) Every two days, disassemble the R. C. S. and clean all components in the upper level of a
dishwasher
Warranty
Delonghi warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. During this period, Delonghi will either repair or
replace, at its discretion, any defective product at no charge to the owner. Replacement products or repaired parts will be guaranteed for only the unexpired portion of the original
warranty or six months, whichever is greater. This limited warranty does not apply to any defect resulting from accident, misuse, improper maintenance, or normal wear and tear. Any
defect resulting from the usage of non genuine Nespresso capsules will not be covered by this warranty. Except to the extent allowed by applicable law, the terms of this limited warranty
do not exclude, restrict
or modify, and are in addition to, the mandatory statutory rights applicable to the sale of the product to you. If you believe your product is defective, contact Nespresso for instructions on
where to send or bring it for repair. Please visit our website at nespresso.com to discover more about Nespresso
Specifications
P
max
Once the rinsing process is finished, the
machine switches off. Clean the machine
using a damp cloth. You have now finished
descaling the machine.
9
10
11 12
Rinsing process Rinse and fill water with
fresh potable water up to MAX level.
Rinsing process Place one container of
minimum 1 litre under both the coffee
outlet and the hot water spout.
PRESS to confirm.
The rinsing cycle continues trough the coffee
outlet, hot water spout and drip tray until the
water tank is empty.
Water hardness setting
1
programmed buttons blinks 3 times: water hardness is set
i
1”
2 3 4
1
2
3
4
5
Place the water hardness sticker under
water for 1 second.
The number of red squares indicates
the water harness level.
Set the value accordinglyEnter the menu, browse the options and select
WATER HARDNESS.
You will be guided to set the value.
Follow machine display instructions.
max
max
Kg
11 12
 19 
EUR,AUS,NZ: 220240 V, 50/60 Hz, 1300 W
US/CA: 120 V, 60 Hz, 1200 W
19 bar
6.5 kg
1,38 litre
500 ml
13-16 capsules
l=19,4 cm . L=33,2 cm . h=27,4 cm
Troubleshooting
Contact the Nespressso Club
For any additional information, in case of problems
or simply to seek advise, call the Nespresso Club.
Contact details of the Nespresso Club can be found
in the 'Welcome to Nespresso' folder in your
machine box or at nespresso.com
No light on display
Check the mains, plug, voltage, and fuse. In case of problems, call the Nespresso Club.
Coffee comes out very slowly.
Flow speed depends on the coffee variety.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Coffee is not hot enough.
Preheat cup.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Capsule area is leaking (water in capsule container).
Position capsule correctly. If leakages occur, call the Nespresso Club.
Irregular blinking.
Send appliance to repair or call the Nespresso Club.
No coffee, just water runs out (despite inserted capsule).
In case of problems, call the Nespresso Club.
Lever cannot be closed completely
Empty capsule container. Make sure that no capsule is blocked inside the capsule container.
Quality of milk froth is not up to standard
1) For a perfect milk froth, use skimmed or semi-skimmed milk at refrigerator temperature (about 4° C)
2) Rinse after each milk based preparation. Place a recipient under milk outlet, rotate the milk
regulator knob until “CLEAN” position.
3) Every two days, disassemble the R. C. S. and clean all components in the upper level of a
dishwasher
Warranty
Delonghi warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. During this period, Delonghi will either repair or
replace, at its discretion, any defective product at no charge to the owner. Replacement products or repaired parts will be guaranteed for only the unexpired portion of the original
warranty or six months, whichever is greater. This limited warranty does not apply to any defect resulting from accident, misuse, improper maintenance, or normal wear and tear. Any
defect resulting from the usage of non genuine Nespresso capsules will not be covered by this warranty. Except to the extent allowed by applicable law, the terms of this limited warranty
do not exclude, restrict
or modify, and are in addition to, the mandatory statutory rights applicable to the sale of the product to you. If you believe your product is defective, contact Nespresso for instructions on
where to send or bring it for repair. Please visit our website at nespresso.com to discover more about Nespresso
Specifications
P
max
Once the rinsing process is finished, the
machine switches off. Clean the machine
using a damp cloth. You have now finished
descaling the machine.
9
10
11 12
Rinsing process Rinse and fill water with
fresh potable water up to MAX level.
Rinsing process Place one container of
minimum 1 litre under both the coffee
outlet and the hot water spout.
PRESS to confirm.
The rinsing cycle continues trough the coffee
outlet, hot water spout and drip tray until the
water tank is empty.
Water hardness setting
1
programmed buttons blinks 3 times: water hardness is set
i
1”
2 3 4
1
2
3
4
5
Place the water hardness sticker under
water for 1 second.
The number of red squares indicates
the water harness level.
Set the value accordinglyEnter the menu, browse the options and select
WATER HARDNESS.
You will be guided to set the value.
Follow machine display instructions.
max
max
Kg
11 12
~4.5 
0.9 і
0.35 і
17.3  25.8 
32 
193
7484_UM_LATTISSIMA_RESTYLE_Z2A.indb 193 03.10.14 14:49

DeLonghi NESPRESSO Lattissima Touch Specifications

General

Milk tank	Yes
Product type	Capsule coffee machine
Built-in grinder	No
Capacity in cups	- cups
Milk adding type	Automatic
Number of spouts	1
Coffee input type	Coffee capsule
Coffee maker type	Fully-auto
Milk tank capacity	0.35 L
Appliance placement	Countertop
Brand compatibility	Nespresso
Water tank capacity	0.9 L
Maximum operating pressure	19 bar
Reservoir for brewed coffee	Cup
Control type	Touch
Product color	White
Housing material	-
Capsule magazine capacity	10 capsules
Fully automatic	Coffee & Milk
AC input voltage	220–240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	320 mm
Width	173 mm
Height	258 mm
Weight	4500 g
