DeLonghi NESPRESSO Lattissima Touch User Manual

EN
FR
Pas de lumière sur les touches et voyants.
➔ Vériez la prise, la che, la tension, le fusible. En cas de problème, appelez le Club Nespresso.
Pas de café, pas d'eau.
➔ Le réservoir d'eau est vide: remplissez le.
➔ Détartrez si nécessaire, voir le paragraphe Détartrage.
Le café s'écoule très lentement.
➔ La vitesse d'écoulement dépend de la variété de café.
➔ Détartrez si nécessaire, voir le paragraphe Détartrage.
Pas de café, seulement de l'eau coule (malgré l'insertion d'une capsule).
➔ En cas de problème, conez l'appareil en réparation ou appelez le Club Nespresso.
Le café n'est pas assez chaud.
➔ Préchauez les tasses.
➔ Détartrez si nécessaire, voir le paragraphe Détartrage.
Fuite au niveau la caspule (eau dans le bac à capsules).
➔ Si la capsule est correctement mise en place, appelez le Club Nespresso.
Clignotements irréguliers.
➔ Conez l'appareil en réparation ou appelez le Club Nespresso.
Toutes les touches clignotent simultanément pendant 10 secondes et la
machine s'éteint.
➔ Alarme Panne : Conez l'appareil en réparation ou appelez le Club Nespresso.
Les 6 touches clignotent rapidement et la machine est prête.
➔ Le réservoir est vide.
Les alertes détartrage et netoyage clignotent.
➔ La machine est en mode Menu, appuyez simultanément sur les touches Latte Macchiato et Mousse de lait
pendant 3 secondes, ou attendez 30 secondes pour qu'elle sorte automatiquement du mode Menu.
L'alerte détartrage est orange xe et les touches café fonctionnent
(Alerte détartrage niveau 1).
➔ L'alerte détartrage se déclenche en fonction de la consommation. Détartrez la machine.
L'alerte détartrage clignote en orange et les touches café fonctionnent
(Alerte détartrage niveau 2).
➔ Le détartrage n'a pas été fait correctement. Détartrez la machine.
L'alerte détartrage clignote en orange et la touche Mousse de lait est
éclairée en permanence.
➔ La machine est en mode détartrage. Appuyez la touche Mousse de lait chaude pour commencer le
détartrage.
L'alerte détartrage est orange xe et les touches café ne fonctionnent plus
(Alerte détartrage niveau 3).
➔ La machine est trop entartrée, elle est bloquée. Détartrez la machine.
L'alerte nettoyage est orange xe.
➔ Rincez le système de lait.
Toutes les touches café et recettes clignotent alternativement.
➔ La machine surchaue, attendez qu'elle refroidisse.
➔ L'appareil est bloqué pour 10 minutes environ suite à une vidange.
Le levier ne se ferme pas complètement.
➔ Videz le bac à capsules. Assurez-vous qu'aucune capsules n'est bloquée dans le bac à capsules.
La mousse de lait est insusante.
➔ Utilisez du lait écrémé ou demi-écrémé à température du réfrigérateur ( 4° C environ).
➔ Rincez le système après chaque préparation (voir le paragraphe nettoyage à la main du R.C.S.).
➔ Détartrez la machine (voir le paragraphe Détartrage).
➔ N'utilisez pas de lait gelé.
Je ne peux pas entrer dans le Mode Menu.
➔ Enlevez le pot à lait.
➔ Assurez-vous d'appuyer simultanément pendant 3 secondes sur les touches Latte Macchiato et
Mousse de Lait.
➔ Enlevez l'embout de détartrage.
DÉPANNAGE
SPECIFICATIONS/
SPÉCIFICATIONS
LATTISSIMA TOUCH
EUR,AUS,NZ: 220240 V, 50/60 Hz, 1300 W
US/CA: 120 V, 60 Hz, 1200 W
19 bar
6.5 kg
1,38 litre
500 ml
13-16 capsules
l=19,4 cm . L=33,2 cm . h=27,4 cm
Troubleshooting
Contact the Nespressso Club
For any additional information, in case of problems
or simply to seek advise, call the Nespresso Club.
Contact details of the Nespresso Club can be found
in the 'Welcome to Nespresso' folder in your
machine box or at nespresso.com
No light on display
Check the mains, plug, voltage, and fuse. In case of problems, call the Nespresso Club.
Coffee comes out very slowly.
Flow speed depends on the coffee variety.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Coffee is not hot enough.
Preheat cup.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Capsule area is leaking (water in capsule container).
Position capsule correctly. If leakages occur, call the Nespresso Club.
Irregular blinking.
Send appliance to repair or call the Nespresso Club.
No coffee, just water runs out (despite inserted capsule).
In case of problems, call the Nespresso Club.
Lever cannot be closed completely
Empty capsule container. Make sure that no capsule is blocked inside the capsule container.
Quality of milk froth is not up to standard
1) For a perfect milk froth, use skimmed or semi-skimmed milk at refrigerator temperature (about 4° C)
2) Rinse after each milk based preparation. Place a recipient under milk outlet, rotate the milk
regulator knob until “CLEAN” position.
3) Every two days, disassemble the R. C. S. and clean all components in the upper level of a
dishwasher
Warranty
Delonghi warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. During this period, Delonghi will either repair or
replace, at its discretion, any defective product at no charge to the owner. Replacement products or repaired parts will be guaranteed for only the unexpired portion of the original
warranty or six months, whichever is greater. This limited warranty does not apply to any defect resulting from accident, misuse, improper maintenance, or normal wear and tear. Any
defect resulting from the usage of non genuine Nespresso capsules will not be covered by this warranty. Except to the extent allowed by applicable law, the terms of this limited warranty
do not exclude, restrict
or modify, and are in addition to, the mandatory statutory rights applicable to the sale of the product to you. If you believe your product is defective, contact Nespresso for instructions on
where to send or bring it for repair. Please visit our website at nespresso.com to discover more about Nespresso
Specifications
P
max
Once the rinsing process is finished, the
machine switches off. Clean the machine
using a damp cloth. You have now finished
descaling the machine.
9
10
11 12
Rinsing process Rinse and fill water with
fresh potable water up to MAX level.
Rinsing process Place one container of
minimum 1 litre under both the coffee
outlet and the hot water spout.
PRESS to confirm.
The rinsing cycle continues trough the coffee
outlet, hot water spout and drip tray until the
water tank is empty.
Water hardness setting
1
programmed buttons blinks 3 times: water hardness is set
i
1”
2 3 4
1
2
3
4
5
Place the water hardness sticker under
water for 1 second.
The number of red squares indicates
the water harness level.
Set the value accordinglyEnter the menu, browse the options and select
WATER HARDNESS.
You will be guided to set the value.
Follow machine display instructions.
max
max
Kg
11 12
EUR, AUS, NZ: 220-240 V,
50/60 Hz, 1400 W
EUR,AUS,NZ: 220240 V, 50/60 Hz, 1300 W
US/CA: 120 V, 60 Hz, 1200 W
19 bar
6.5 kg
1,38 litre
500 ml
13-16 capsules
l=19,4 cm . L=33,2 cm . h=27,4 cm
Troubleshooting
Contact the Nespressso Club
For any additional information, in case of problems
or simply to seek advise, call the Nespresso Club.
Contact details of the Nespresso Club can be found
in the 'Welcome to Nespresso' folder in your
machine box or at nespresso.com
No light on display
Check the mains, plug, voltage, and fuse. In case of problems, call the Nespresso Club.
Coffee comes out very slowly.
Flow speed depends on the coffee variety.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Coffee is not hot enough.
Preheat cup.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Capsule area is leaking (water in capsule container).
Position capsule correctly. If leakages occur, call the Nespresso Club.
Irregular blinking.
Send appliance to repair or call the Nespresso Club.
No coffee, just water runs out (despite inserted capsule).
In case of problems, call the Nespresso Club.
Lever cannot be closed completely
Empty capsule container. Make sure that no capsule is blocked inside the capsule container.
Quality of milk froth is not up to standard
1) For a perfect milk froth, use skimmed or semi-skimmed milk at refrigerator temperature (about 4° C)
2) Rinse after each milk based preparation. Place a recipient under milk outlet, rotate the milk
regulator knob until “CLEAN” position.
3) Every two days, disassemble the R. C. S. and clean all components in the upper level of a
dishwasher
Warranty
Delonghi warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. During this period, Delonghi will either repair or
replace, at its discretion, any defective product at no charge to the owner. Replacement products or repaired parts will be guaranteed for only the unexpired portion of the original
warranty or six months, whichever is greater. This limited warranty does not apply to any defect resulting from accident, misuse, improper maintenance, or normal wear and tear. Any
defect resulting from the usage of non genuine Nespresso capsules will not be covered by this warranty. Except to the extent allowed by applicable law, the terms of this limited warranty
do not exclude, restrict
or modify, and are in addition to, the mandatory statutory rights applicable to the sale of the product to you. If you believe your product is defective, contact Nespresso for instructions on
where to send or bring it for repair. Please visit our website at nespresso.com to discover more about Nespresso
Specifications
P
max
Once the rinsing process is finished, the
machine switches off. Clean the machine
using a damp cloth. You have now finished
descaling the machine.
9
10
11 12
Rinsing process Rinse and fill water with
fresh potable water up to MAX level.
Rinsing process Place one container of
minimum 1 litre under both the coffee
outlet and the hot water spout.
PRESS to confirm.
The rinsing cycle continues trough the coffee
outlet, hot water spout and drip tray until the
water tank is empty.
Water hardness setting
1
programmed buttons blinks 3 times: water hardness is set
i
1”
2 3 4
1
2
3
4
5
Place the water hardness sticker under
water for 1 second.
The number of red squares indicates
the water harness level.
Set the value accordinglyEnter the menu, browse the options and select
WATER HARDNESS.
You will be guided to set the value.
Follow machine display instructions.
max
max
Kg
11 12
Max/Max. 19 bar
EUR,AUS,NZ: 220240 V, 50/60 Hz, 1300 W
US/CA: 120 V, 60 Hz, 1200 W
19 bar
6.5 kg
1,38 litre
500 ml
13-16 capsules
l=19,4 cm . L=33,2 cm . h=27,4 cm
Troubleshooting
Contact the Nespressso Club
For any additional information, in case of problems
or simply to seek advise, call the Nespresso Club.
Contact details of the Nespresso Club can be found
in the 'Welcome to Nespresso' folder in your
machine box or at nespresso.com
No light on display
Check the mains, plug, voltage, and fuse. In case of problems, call the Nespresso Club.
Coffee comes out very slowly.
Flow speed depends on the coffee variety.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Coffee is not hot enough.
Preheat cup.
Perform a self check of the machine. Enter the menu list and select Maintenance. Follow instruction
Capsule area is leaking (water in capsule container).
Position capsule correctly. If leakages occur, call the Nespresso Club.
Irregular blinking.
Send appliance to repair or call the Nespresso Club.
No coffee, just water runs out (despite inserted capsule).
In case of problems, call the Nespresso Club.
Lever cannot be closed completely
Empty capsule container. Make sure that no capsule is blocked inside the capsule container.
Quality of milk froth is not up to standard
1) For a perfect milk froth, use skimmed or semi-skimmed milk at refrigerator temperature (about 4° C)
2) Rinse after each milk based preparation. Place a recipient under milk outlet, rotate the milk
regulator knob until “CLEAN” position.
3) Every two days, disassemble the R. C. S. and clean all components in the upper level of a
dishwasher
Warranty
Delonghi warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. During this period, Delonghi will either repair or
replace, at its discretion, any defective product at no charge to the owner. Replacement products or repaired parts will be guaranteed for only the unexpired portion of the original
warranty or six months, whichever is greater. This limited warranty does not apply to any defect resulting from accident, misuse, improper maintenance, or normal wear and tear. Any
defect resulting from the usage of non genuine Nespresso capsules will not be covered by this warranty. Except to the extent allowed by applicable law, the terms of this limited warranty
do not exclude, restrict
or modify, and are in addition to, the mandatory statutory rights applicable to the sale of the product to you. If you believe your product is defective, contact Nespresso for instructions on
where to send or bring it for repair. Please visit our website at nespresso.com to discover more about Nespresso
Specifications
P
max
Once the rinsing process is finished, the
machine switches off. Clean the machine
using a damp cloth. You have now finished
descaling the machine.
9
10
11 12
Rinsing process Rinse and fill water with
fresh potable water up to MAX level.
Rinsing process Place one container of
minimum 1 litre under both the coffee
outlet and the hot water spout.
PRESS to confirm.
The rinsing cycle continues trough the coffee
outlet, hot water spout and drip tray until the
water tank is empty.
Water hardness setting
1
programmed buttons blinks 3 times: water hardness is set
i
1”
2 3 4
1
2
3
4
5
Place the water hardness sticker under
water for 1 second.
The number of red squares indicates
the water harness level.
Set the value accordinglyEnter the menu, browse the options and select
WATER HARDNESS.
You will be guided to set the value.
Follow machine display instructions.
max
max
Kg
11 12
~ 4.5 kg
0.9 L/litre
0.35 L/litre
17.3 cm 25.8 cm
32 cm
30
7484_UM_LATTISSIMA_RESTYLE_Z2A.indb 30 03.10.14 14:48

DeLonghi NESPRESSO Lattissima Touch Specifications

General

Milk tank	Yes
Product type	Capsule coffee machine
Built-in grinder	No
Capacity in cups	- cups
Milk adding type	Automatic
Number of spouts	1
Coffee input type	Coffee capsule
Coffee maker type	Fully-auto
Milk tank capacity	0.35 L
Appliance placement	Countertop
Brand compatibility	Nespresso
Water tank capacity	0.9 L
Maximum operating pressure	19 bar
Reservoir for brewed coffee	Cup
Control type	Touch
Product color	White
Housing material	-
Capsule magazine capacity	10 capsules
Fully automatic	Coffee & Milk
AC input voltage	220–240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	320 mm
Width	173 mm
Height	258 mm
Weight	4500 g
