5/ TROUBLESHOOTING
5.1 TYXIA 2330 TRANSMITTER SWITCH
Removing a motor or funconal receiver
❶ Press the T1 buon for 3 seconds,
then successively press the
buon
to select the motor to remove.
❷ Press the buon:
The roller shuer starts up, the associaon is removed.
❸ Press the T1 buon.
Removing all motors or receivers that are out of service, missing from the site or
switched o
❶ Press and hold the T1 buon for 3 seconds.
❷ Press the
and buons.
❸ Press the T1 buon.
Reset / Removal of all motors or receivers
❶ Press and hold the T1 buon for 3 seconds.
❷ Simultaneously press the and buons,
unl the LED ashes once (red then green).
❸ Press the T1 buon.
Baery replacement
3
2x
Green
2x
... ... ...
Green
4
> 3s
T1
T1
2
3
2x
Green
2x
... ... ...
Green
4
> 3s
T1
T1
2
3
2x
Green
2x
... ... ...
Green
4
> 3s
T1
T1
2
5.2 SIGNALS AND POSSIBLE FAULTS ON THE TYDOM 1.0
LED System status
Green and
ashing
System accessible locally and remotely, user logged in
Green on and
steady
System accessible locally and remotely
Orange and
ashing
System accessible locally, user logged in
Orange and
steady
System accessible locally
Red and steady
No allocated IP address
Diagnosc funcon
Briey press the buon (viewing the LED for 10 seconds)
Yellow and ashing Fixed IP OK
Blue and ashing DHCP OK / Upnp OK
Blue and ashing (2x)
DHCP OK / Upnp Error
Check that the Upnp is acvated on the BOX
Blue and ashing (3x)
DHCP in progress
Check that the DHCP is acvated on the BOX
!
CR 2430
2s
The red LED ashes each me you press = Baery fault
